VP-200K, VP-300K, VP-400K - Connecting the VP-300K

5 Connecting the VP-300K

Always switch off the power to each device before connecting it to your

product. After connecting your product, connect its power and then

switch on the power to each device.

To connect the VP-300K as illustrated in the example in Figure 4:

1. Connect a computer graphics source to the INPUT 15-pin HD connector.

2. Connect the OUTPUT 15-pin HD connectors to up to three acceptors (two for

the VP-200K and four for the VP-400K), as follows:

 Connect the OUTPUT 1 connector to acceptor 1 (for example, a

projector)

 Connect the OUTPUT 2 connector to acceptor 2 (for example, an LCD

monitor)

 Connect the OUTPUT 3 connector to acceptor 3 (for example, a

display)

3. Connect the 5V DC power adapter (wall transformer) to the 5V DC socket

and connect the transformer to the mains electricity.

4. If required, set the:

 Hs and Vs switches

 ID Bit switch to ON
