Your XGA Differential Amplifier / DA

Table 1: Features and Functions of the VP-200Dxl XGA Differential Amplifier / DA

# Feature Function

1 12V DC +12V DC connector for powering the unit

2 OUTPUT 1 HD15F Connector Connect to the VGA/XGA acceptor 1

3 OUTPUT 2 HD15F Connector Connect to the VGA/XGA acceptor 2

4 ON LED Illuminates when receiving power

5 INPUT HD15F Connector Connect to the VGA/XGA source

6 ID Bit Button Pushing in selects the ID BIT, releasing deactivates the ID BIT

(when outputting the input signal from a notebook connected to an

external VGA monitor

)

7 EQ. Control Knob Adjusts the video EQ. (equalization) compensation potentiometer

8 LEVEL Control Knob Adjusts the video signal level potentiometer

4.1 Connecting the

XGA Differential Amplifier / DA

To connect the VP-200Dxl, as the example in Figure 2 illustrates, do the

following:

1. Connect a XGA source (for example, a PC graphics card) to the INPUT

HD15F connector.

2. Release the ID Bit button

3. Connect the OUTPUT (HD15F connectors) to up to 2 acceptors, as

follows:

 Connect the OUTPUT 1 (HD15F connector) to the acceptor 1 (for

example, a PC monitor)

 Connect the OUTPUT 2 (HD15F connector) to the acceptor 2 (for

example, a projector)

4. Connect the 12V DC power adapter to the power socket and connect the

adapter to the mains electricity.

5. Adjust the video EQ. (equalization) compensation and/or the video signal

level, if required.

1 Sometimes notebook computers refuse to output a VGA signal to an external VGA monitor if they do not detect the ID Bit

as ON (pin # 4 on the VGA connector). Set the ID Bit to ON using this button so that the notebook will output to an external

VGA monitor

2 However, if the source is a notebook (instead of a PC graphics card), push in the ID Bit button
