Operating the VS-121HC Switcher/Transcoder
8
Figure 2: Connecting the VS-121HC Switcher / Transcoder
7 Operating the VS-121HC Switcher/Transcoder
You can operate the VS-121HC using:
• The front panel buttons (see section
7.1)
• The RS-232 port (see section
7.2)
• The RS-485 port (see section
7.3)
• An Ethernet network (see section
7.4)
• The RC-IR2 remote control transmitter
1
7.5 (see section )
This section also describes:
• How to set the DIP-switches (see section
7.6)
• How to operate the VS-121HC in tandem with the VS-121HCA
(section 7.7
)
1 Refer to the separate user manual. Download it from our Web site at http://www.kramerelectronics.com
