![Kramer K424F [2/2] Secure kvm combiner specification](/views2/1152568/page2/bg2.png)
K404F • K424F • K404D
© 2013 High Sec Labs Ltd. All rights reserved. All trade names are trademarks or registered trademarks of respective manufacturers listed.
Specications are subjected to change without prior notice. Multiple patents pending. HDC08695 Rev 1.3
SECURE KVM
COMBINER
SPECIFICATION
PART NUMBER K404F K424F K404D
No. of Computers 4 4 4
CONSOLE PORTS (DEVICES)
Console Mouse and Keyboard Ports
USB Type A female connector or PS/2 Mini-DIN 6 pin female connector (1 each)
Console Display Ports
1 DVI-D single-link female connector
Resolution up to 1920x1200
2 DVI-D single-link female connector
Resolution up to 1920x1200
1 DisplayPort female connector
Resolution up to 1920x1200
Console Audio Jack 3.5mm Female
Console CAC Input USB Type A
COMPUTER PORTS
Computer Display Ports 1 DVI-D single-link female connector.
Computer Audio Jack 3.5mm Female
Computer Keyboard/Mouse Ports USB Type B
Computer CAC Ports USB Type B
PHYSICAL
Dimensions 320(W) x 130 (D) x 52 (H) mm / 12.8 (W) x 5.2 (D) x 2 (H) inch
Weight 1.53 Kg. (3.4 lbs.)
POWER
Power Requirements 12V DC, 5A (max) power adapter with center-pin-positive polarity
AC Input 100 to 240VAC
Power Type External
ENVIRONMENTAL
Operating Temperature 32° to 104° F (0° to 40° C)
Storage Temperature -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
CERTIFICATION
Security Accreditation Common Criteria EAL 4+ ALC_FLR.3
GENERAL INFORMATION
Made In Israel
Product life-cycle 10 years
Warranty 2 Years
OUTPUT DISPLAY RESOLUTIONS SUPPORTED
RESOLUTION K404F K424F K404D
1024x768 (4:3)
✔ ✔ ✔
1280x800 (8:5)
✔ ✔ ✔
1280x1024 (4:3)
✔ ✔ ✔
1680x1050 (8:5)
✔ ✔ ✔
1920x1080 (16:9)
✔ ✔ ✔
1920x1200 (8:5)
✔ ✔ ✔
2x1920x1080 (16:9)
✔
2x1920x1200 (8:5)
✔
2560 x 1440 (16:9)
✔
2560 x 1600 (8:5)
✔
K424F Back Panel
K404F Back Panel
K404D Back Panel
K424F Secure KVM Combiner
Keyboard
Audio
RDC
Computers
Mouse
Secondary DisplayPrimary Display
Channel 2 Channel 3
Channel 4
Channel 1Setup Channel 2 Channel 3 Channel 4 1 2 3 ? Scale Tile
Channel 1
K424F Secure KVM Combiner
FREEZE
DPP
4 3 2 1
34 2 1
