Kramer K502 [2/2] Specification
![Kramer K502 [2/2] Specification](/views2/1152574/page2/bg2.png)
K502 • K504 • K504E • K 5 2 4 E
© 2015 High Sec Labs Ltd. All rights reserved. All trade names are trademarks or registered trademarks of respective manufacturers listed.
Specications are subjected to change without prior notice. Multiple patents pending. HDC08687 Rev. 1.3
SPECIFICATION
Part Number
K502 K504 K504E K524E
Numbers of Computers 2 4 4 4
Number of Displays 1 1 1 2
Resolution Supported All DisplayPort 1.2 resolutions up to 3840×2160 by 30 bpp @ 60Hz. Supports 17.28 Gbps @ a 4-lane link.
CONSULE PORTS
Console Mouse and Keyboard Ports
2* USB Type-A female connector or 2* PS/2 Mini-DIN 6-pin female connector (1 port for mouse and 1 port for
keyboard)
Console Display Ports DisplayPort 1.1 and 1.2 DisplayPort 1.1 and 1.2 2 x DisplayPort 1.1 and 1.2
Console Audio Jack 3.5mm female
Console DPP Input N/A N/A USB Type A USB Type A
COMPUTER PORTS
Computer Display Ports 1 x DisplayPort 1.1 and 1.2 1 x DisplayPort 1.1 and 1.2 1 x DisplayPort 1.1 and 1.2 2 x DisplayPort 1.1 and 1.2
Computer Audio Jack 3.5mm female 3.5mm female 3.5mm female 3.5mm female
Computer Keyboard/Mouse Ports USB Type B USB Type B USB Type B USB Type B
Computer CAC Ports USB Type B USB Type B USB Type B USB Type B
PHYSICAL
Dimensions
136 (W) x 61 (D) x 36 (H)
mm / 5.4 (W) x 24.6 (D) x
1.46 (H) inch
320 (W) x 130 (D) x 52 (H)
mm / 12.8 (W) x 5.2 (D) x 2
(H) inch
320 (W) x 130 (D) x 52 (H)
mm / 12.8 (W) x 5.2 (D) x 2
(H) inch
320 (W) x 130 (D) x 65 (H)
mm / 12.8 (W) x 5.2 (D) x
2.6 (H) inch
Weight 0.36 Kg. (0.79 lbs.) 1.47 Kg. (3.2 lbs.) 1.47 Kg. (3.2 lbs.) 1.47 Kg. (3.2 lbs.)
POWER
Power Requirements 100–240VAC, 1A Max, 50/60Hz
AC Input 100-240VAC
Power Type External
ENVIRONMENTAL
Operating Temperture 32° to 104° F (0° to 40° C)
Storage Temperature -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
CERTIFICATION
Security Common Criteria EAL 4+ ALC_FLR.3
Safety/EMC EN 55022, EN 55024, EN 61000-3-2, FCC Part 15
GENERAL INFORMATION
Product Life-Cycle 10 Years
Warranty 2 years
K502 - Back Panel
K504 - Back Panel
K524E - Back Panel
K504E - Back Panel
