Kramer RC-108 [5/34] Getting started
![Kramer RC-108 [5/34] Getting started](/views2/1152639/page5/bg5.png)
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
Table 3: Connecting a Power Adapter to a System
The quantity of machines in a
system
Recommended Power
Adapter (12V DC)
Part Number
Up to two TP-107AVR units
1.25A EU/US:
UK:
Japan:
2535-000005
2535-000006
2535-700005
Three to four TP-107AVR units
2.1A EU/US:
UK:
Japan:
EU/US: 2535-000251
UK: 2535-025121
Japan: 2535-700251
Five to eight TP-107AVR units
1
5A
EU/US/UK
2
Japan:
: 2535-000635
2535-700635
2 Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
• Review the contents of this user manual
• Use Kramer high performance high resolution cables
3
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
1 If more than eight units are used, it is recommended to connect two 5A power adapters to the system
2 A desktop power supply with a DC plug. This power supply requires an AC power cord; use the power cables with a US
plug for the US, an EU plug for Europe, and a UK plug for the UK
3 The complete list of Kramer cables is on our Web site at
http://www.kramerelectronics.com
