8
PT-5T/R - Technical Specifications
5 Technical Specifications
INPUTS:
PT-5T: 1 IR receiver on a
3.5mm mini jack
PT-5R: 1 RJ-45
OUTPUTS:
PT-5T: 2 IR emitters on
3.5mm mini jacks, 1 RJ-45
PT-5R: 3 IR emitters on
3.5mm mini jacks
MAXIMUM OPERATING
DISTANCE:
250m (820ft)
CARRIER FREQUENCY:
36-40kHz
POWER CONSUMPTION:
5V DC; PT-5T: 7mA, PT-5R: 6mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
5.0cm x 6.6cm x 2.3cm (1.97" x 2.6" x 0.91") W, D, H
WEIGHT:
0.15kg (0.33lbs) approx.
ACCESSORIES:
Power adapter
1 IR Receiver with 2m cable and 3.5mm mini jack
5 IR Emitters with 2m cables and 3.5mm mini jacks
OPTIONS:
RK-4PT 19” Rack Adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com
