Overview

3 Overview

The VP-100 VGA/XGA to RGBHV Converter is a high performance format

converter for computer graphics video signals. It converts a computer

graphics video signal on a 15-pin HD connector to either RGBS, RGsB, or

RGBHV video signals on BNC connectors and simultaneously outputs it to

an RGBHV acceptor and a local display.

In particular, the VP-100:

 Provides local monitor loop-through, buffering, amplification, and sync

processing for remote acceptor applications

 Accepts all typical graphic modes, including VGA, SVGA, XGA, SXGA,

and UXGA and outputs RGsB, RGBS, or RGBHV

 Has a bandwith of 350MHz that ensures transparent operation at multiple

resolutions including UXGA

 Allows looping with a termination switch

 Includes cable EQ. control, Hs and Vs shift control and ID BIT control

To achieve the best performance:

 Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables)

 Avoid interference from neighboring electrical appliances and position

your VP-100 away from moisture, excessive sunlight and dust

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

1 For example: model number AD2512C, part number 2535-000251
