Kramer TP-590RXR [2/2] Step 4 set the dip switches

Step 5: Connect the power

If the is not connected to a TP-590TXR, connect the power adapter to the TP-590RXR and

plug the adapter into the mains electricity.

TP-590RXR

TP-590RXR Quick Start (P/N: 2900-300500QS REV 1)

2 9 0 0 - 3 0 0 5 0 0 QS

P/N:

Rev:

For optimum range and performance use Kramer's BC-DGKat623 and BC-DGKat7a23 DGKat, and BC-HDKat6a

HDBaseT cables.

Step 4: Set the DIP-switches

Feature

Function

DIP-switch

Extended Range

Enables extended range when used with

either the TP-590TXR or other transmitters

that support extended range

On—Enable

Off—Disable

Reserved

EDID Lock

Locks the current EDID and prevents

automatic EDID acquisition

On—Lock EDID

Off—Automatic EDID

acquisition

Reserved

A DIP-switch that is down is on, up is off (default)
