PSE-1 - Technical Specifications
9
7 Technical Specifications
INPUT/OUTPUT:
1 HDBaseT/LAN + POE on an RJ-45 connector
1 HDBaseT/LAN on an RJ-45 connector
OPERATION BANDWIDTH:
Up to 10.2Gbps (3.4Gbps per data channel)
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI, HDCP
INDICATOR LEDS:
ON, POE STATUS
POWER SOURCE:
48V DC
POWER PROVISION:
Up to 13W
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
–40° to +70°C (–40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
COOLING:
Convection, vents
ENCLOSURE TYPE:
Aluminium
DIMENSIONS:
12.1cm x 6.99cm x 2.47cm (4.76" x 2.75" x 0.97") W, D, H
RACK MOUNT:
With optional adapter
FURNITURE MOUNT:
With included rubber feet
PRODUCT WEIGHT:
0.23 kg (0.51lbs) approx.
SHIPPING WEIGHT:
0.72kg (1.59lbs) approx.
VIBRATION:
ISTA 1A in carton (International Safe Transit Association)
SAFETY REGULATORY
COMPLIANCE:
CE, c-UL, UL
EMI/EMC REGULATORY
COMPLIANCE:
CE, C-tick, FCC Class A, ICES, KCC, VCCI
ENVIRONMENTAL
REGULATORY COMPLIANCE:
Complies with appropriate requirements of RoHs and
WEEE
INCLUDED ACCESSORIES:
Power supply
OPTIONS:
RK-3T 19” rack adapter
WARRANTY:
7 years parts and labor
Specifications are subject to change without notice at http://www.kramerelectronics.com
