616T, 616R - Overview

3 Overview

The 616T and 616R are a small and lightweight fiber optic transmitter and receiver

pair that transmit uncompressed resolutions up to WQXGA (2560x1600 @60Hz)

or WQUXGA (3840x2400 @33Hz vertical refresh rate) over dual link DVI to a

range of up to 500 meters (1640 feet) over duplex multimode fiber optic cable with

two LC connectors. The 616T converts dual link DVI signals to optical signals that

it transmits to the 616R. The 616R decodes the optical signals back to a dual link

DVI signal.

The 616T and 616R feature:

 A maximum data rate of 13.5Gbps (2.25Gbps per graphic channel)

 Supported resolutions – HDTV: 480p, 720p, 1080p;

Vesa: VGA to WQUXGA @33Hz (XGA not supported)

 A range of up to 500m (1640ft) (multimode)

 Duplex multimode fiber optic cable with two LC connectors (Kramer

C-2LC/2LC series)

 EDID capture that copies and stores the EDID from a display device (616T)

 Standards compliance - supports DVI1.0, fully implemented by fiber-optic

communication and DDC2B by virtual DDC

 Compliance with the limits for a Class A digital device, pursuant to part 15

and 2 of FCC and CE

 Laser standards compliance - IEC 60825-1, FDA 21CFR1040;

Laser Class 1: Safety of laser products

 No EMI/RFI from the interconnecting cable

 HDTV compatibility, no HDCP compliance

 Two external 5V DC power adapters (supplied)

 NanoTools size
