4 Connecting the 671T, 671R

Always switch off the power to each device before connecting it to your

671T, 671R. After connecting your 671T, 671R, connect its power and

then switch on the power to each device.

Avoid direct eye exposure into the optic connectors when powered,

although this product is regulated strictly enough to operate under the

Laser Class 3R for eye safety

To connect the 671T and 671R, as illustrated in the example in Figure 3, do the

following:

1. Connect a DVI source (for example a DVD player) to the DVI IN connector.

2. Connect the DVI OUT connector to a DVI acceptor (for example, an LCD

display).

3. Remove the dust caps and connect the OPTIC CABLE connector of the

671T to the OPTIC CABLE connector of the 671R, via optic OM3 cabling

with SC connectors (maximum range of 2000 meters (over 6560ft)).

4. Connect the 5V DC power adapter to the power socket on each unit and

connect the adapter to the mains electricity (not shown in Figure 3).
