670T, 670RN - Connecting the 670T, 670RN

4 Connecting the 670T, 670RN

Always switch off the power to each device before connecting it to your

670T, 670RN. After connecting your 670T, 670RN, connect its power

and then switch on the power to each device.

Avoid direct eye exposure into the optic connectors when powered,

although this product is regulated strictly enough to operate under the

Laser Class 3R for eye safety

To connect the 670T and 670RN, as illustrated in the example in Figure 3, do the

following:

1. Connect an HDMI source (for example a Blu-ray disc player) to the HDMI IN

connector.

2. Connect the HDMI OUT connector to an HDMI acceptor (for example, an

LCD display).

3. Remove the dust caps and connect the OPTIC CABLE connector of the

670T to the OPTIC CABLE connector of the 670RN, via optic OM3 cabling

with SC connectors (maximum range of 1700m (over 5570ft)).

4. Connect the 5V DC power adapter to the power socket on each unit and

connect the adapter to the mains electricity (not shown in Figure 3).
