670T, 670R - Technical Specifications

5 Technical Specifications

670T

670R

INPUTS:

HDMI Connector

1 optical connector

OUTPUTS:

1 optical connector

HDMI Connector

BANDWIDTH:

Supports up to 3.5Gbps bandwidth per graphic channel

COMPLIANCE WITH HDMI

STANDARD:

Supports HDMI using fiber optic communication links and

DDC2B

EXTENSION LIMIT:

1700m (>5570 feet) for 1080p/60Hz

FIBER-OPTIC CONNECTION:

SC connectors for multimode (OM3) fiber cable (not

supplied with the unit)

INSERTION LOSS FROM

TRANSMITTER TO RECEIVER:

Must not exceed 10dB

INDICATOR LEDs:

Video, source, acceptor fiber and on LEDs

POWER CONSUMPTION:

5V DC, 250mA

5V DC, 400mA

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

12cm x 7.95cm x 2.76cm (4.7" x 3.1" x 1.08") W, D, H

WEIGHT:

0.3kg (0.67lbs) approx. each

ACCESSORIES:

2 power supplies (5V/2A), 2 bracket installation kits

Specifications are subject to change without notice at http://www.kramerelectronics.com
