Kramer 613R [11/13] Technical specifications

613T, 613R - Technical Specifications

5 Technical Specifications

INPUTS:

613T: SD/HD/3G HD-SDI on a 75Ω BNC connector

613R: 1 optical ST connector

OUTPUTS:

613T: 1 optical ST connector

613R: SD/HD/3G HD-SDI on a 75Ω BNC connector

MAXIMUM DATA RATE:

Up to 3Gbps

MAXIMUM LENGTH:

30km (19mi) @3G, 1080p 3G-SDI format

FORMAT:

SMPTE 424M: 3G HD-SDI; SMPTE 292M: HD-SDI;

SMPTE 259: SDI, DVB-ASI

RECOMMENDED

FIBER-OPTIC CABLE:

1310, 1550nm single-mode optical fiber with ST

connectors

POWER CONSUMPTION:

5V DC, 1.5A

OPERATING TEMPERATURE:

-20° to 70°C (-4° to 158°F)

STORAGE TEMPERATURE:

-30° to 85°C (-22° to 185°F) ambient

HUMIDITY:

5% to 95% RH

DIMENSIONS:

1.9cm x 8.3cm x 1.0 cm (0.7" x 3.3" x 0.7") W, D, H

WEIGHT:

613T and 613R 0.1kg (0.2lbs) approx.

INCLUDED ACCESSORIES:

2 power supplies

Specifications are subject to change without notice at http://www.kramerelectronics.com
