673T, 673R - Technical Specifications
9
5 Technical Specifications
673T
673R
INPUTS:
SD/HD/3G-HD-SDI/Dual
link, 75Ω on BNC
connectors
1 optical connector
OUTPUTS:
1 optical connector
SD/HD/3G-HD-SDI/Dual link,
75Ω on BNC connectors
BANDWIDTH:
Supports up to 3Gbps bandwidth for each input
FIBER OPTIC RANGE:
Up to 1000m (>3200 feet) for 3G HD-SDI
INPUT CABLE
EQUALIZATION (673T):
350m for SDI, 140m for HD-SDI, 120m for 3G HD-SDI
FIBER OPTIC CONNECTION:
SC connectors for multimode (OM3) fiber cable
INSERTION LOSS FROM
TRANSMITTER TO
RECEIVER:
Must not exceed 10dB
INDICATOR LEDs:
VIDEO, SOURCE, FIBER and ON LEDs
POWER CONSUMPTION:
5V DC, 520mA
5V DC, 780mA
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12cm x 7.95cm x 2.76cm (4.7" x 3.1" x 1.08", W, D, H)
WEIGHT:
0.3kg (0.67lbs) approx. each
INCLUDED ACCESSORIES:
2 power supplies, bracket installation kit
OPTIONS:
RK-3T 19" rack mount
Specifications are subject to change without notice at http://www.kramerelectronics.com
