The VA-1VGAxl can present on its input an EDID from either a display connected

to the output or one of the built-in EDID values.

5.1 Capturing the EDID from a Display Device

To capture the EDID from a display device:

1. Ensure that the rotary switch is in position 0. If it is not, use a small

screwdriver to turn it to 0.

2. Press the EDID capture button.

The ON LED flashes slowly several times.

The new EDID is captured when the LED stops flashing and lights

continuously. If the LED flashes quickly a few times and then lights

continuously, the EDID was not captured and the default EDID is captured.

5.2 Setting a Built-in EDID

To set a built-in EDID:

1. Using a small screwdriver, turn the rotary switch to the required position (see

the table below).

2. Press the EDID CAPTURE button.

The ON LED flashes quickly several times.

The new EDID is captured when the LED stops flashing and lights solid. If

the LED flashes quickly a few times and then goes out, the EDID was not

captured.
