Technical Specifications

6 Technical Specifications

Table 4 includes the technical specifications:

Table 4: Technical Specifications

of the VS-4FW, VS-6FW and VS-8FW

PORTS: VS-4FW: Four 6-pin serial 1394 Ports

VS-6FW: Six 6-pin serial 1394 Ports

VS-8FW: Eight 6-pin serial 1394 Ports

TRANSFER RATE: 100/200/400 Mbps

STANDARDS: Fully supports the provisions of the IEEE 1394-1995 Standard for High

Performance Serial Bus and the P1394a Supplement;

Fully interoperable with FireWire™ and i.LINK™ implementation of IEEE Std 1394;

Fully compliant with OpenHCI requirements;

Provides Six P1394a Fully Compliant Cable Ports at 100/200/400 Megabits per

Second (Mbits/s);

Full P1394a support includes: Connection Debounce, Arbitrated Short Reset,

Multispeed Concatenation, Arbitration Acceleration, Fly-By Concatenation, Port

Disable/Suspend/Resume;

Extended Resume Signaling for Compatibility with Legacy DV Devices;

ESD protection for high-speed data lines to IEC 61000-4-2 (ESD) 15kV (air), 8kV

(contact), IEC 61000-4-5 (Lightning) 12A (8/20us), and IEC 61000-4-4 (EFT) 40A

(5/50ns)

POWER SOURCE: VS-4FW: 12 VDC, 200mA

VS-6FW: 12 VDC, 250mA

VS-8FW: 12 VDC, 300mA

DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98", W, D, H)

WEIGHT: 0.3 kg. (0.67 lbs.) approx.

ACCESSORIES: Power supply, mounting bracket, one 6 pin to 6 pin connector cable

1 Specifications are subject to change without notice
