Kramer Yarden8-C [11/20] Mounting the speakers

Yarden 8-C - Installing the Yarden 8-C Closed-back Ceiling Speakers

4. Routethewiringfromtheamplifiertothespeakers’cutoutholes,takingcare

not to place them next to electrical wires or at least at a distance of about

two feet from an AC line.

Do not nail or staple the speaker wires.

If you are mounting the speakers onto a ceiling tile, remove the ceiling tiles where

you plan to install the speakers. Use the template to trace and then cutout the

speaker hole over an empty box.

The closed-back ceiling speakers are supported by the ceiling mounting kit (two

C-rings and two pairs of tile rails; the tile rails prevent the speakers from falling if

the tile itself comes out or falls apart, as their ends catch onto the T-grid). When

mounting onto the ceiling tiles, use both supports.

Be sure that the tiles can support the speaker. Smaller sized tiles or

fiberglass-type tiles cannot support the weight of the speakers.

When this is the case, the speakers will need additional support.

When mounting onto a sheetrock ceiling, the C-ring alone is used to reinforce the

ceiling material.

5.3 Mounting the Speakers

To mount the Yarden 8-C, do the following:

1. Place the C-ring over the hole cut in the ceilingtile(onthe“ceiling”side).

Place it around the hole so that the tabs are located in parallel to the tile

edges.
