Kramer 900XL Руководства по эксплуатации онлайн
Содержание
- Kramer electronics ltd 1
- User manual 1
- Getting started 4
- Introduction 4
- Recycling kramer products 4
- Overview 5
- Figure 1 900xl power amplifier top front and rear views 6
- Figure 1 figure 2 table 1 and table 2 define the unit 6
- Table 1 900xl power amplifier front and rear functions 6
- Your 900xl power amplifier 6
- Connecting the 900xl power amplifier 8
- Connecting a pc 9
- Operating the 900xl power amplifier 9
- Using the front panel buttons 9
- For an explanation of all control commands see sections 8 and 9 10
- Table 3 900xl technical specification 10
- Technical specifications 10
- To operate your device using serial commands you need to install kramer s control softwar 10
- Using serial commands 10
- Xl technical specifications are shown in table 3 10
- Hex table 11
- Kramer protocol 2000 11
- Note compatibility with kramer s protocol 2000 does not mean that a machine uses all of the commands below each machine uses a sub set of protocol 2000 according to its needs 11
- Table 4 900xl hex table 11
- Table 4 lists the hex values described in section 9 for the 900xl 11
- Table 5 protocol definitions 11
- The 900xl is compatible with kramer s protocol 2000 version 0 0 this rs 232 rs 485 communication protocol uses four bytes of information as defined below for rs 232 a null modem connection between the machine and controller is used the default data rate is 9600 baud with no parity 8 data bits and 1 stop bit 11
- Bit 5 don t care bit 5 don t care 12
- Byte bit 7 defined as 0 12
- Byte bit 7 defined as 1 12
- D destination d destination 0 for sending information to the switchers from the pc 12
- Description input output 12
- For sending to the pc from the switcher 1 for sending to the pc from the switcher 12
- I6 i0 input i6 i0 input 12
- Instruction definition for specific instruction note 12
- Kramer protocol 2000 12
- M4 m0 machine number m4 m0 machine number 12
- N5 n0 instruction n5 n0 instruction 12
- Note all values in the table are decimal unless otherwise stated 12
- O6 o0 output o6 o0 output 12
- Ovr machine number override ovr machine number override 12
- Table 6 instruction codes for protocol 2000 12
- The function to be performed by the switcher s is defined by the instruction 6 bits also if a function is performed via the machine s keyboard then these bits are set with the instruction no that was performed the instruction codes are defined according to the table below instruction no is the value to be set for n5 n0 12
- Used to address machines in a system via their machine numbers when several machines are controlled from a single serial port they are usually configured together with each machine having an individual machine number if the ovr bit is set then all machine numbers will accept implement the command and the addressed machine will reply for a single machine controlled via the serial port always set m4 m0 1 and make sure that the machine itself is configured as machine number 1 12
- When switching i e instruction codes 1 and 2 the input 7 bits is set as the input number which is to be switched similarly if switching is done via the machine s front panel then these bits are set with the input number which was switched for other operations these bits are defined according to the table 12
- When switching ie instruction codes 1 and 2 the output 7 bits is set as the output number which is to be switched similarly if switching is done via the machine s front panel then these bits are set with the output number which was switched for other operations these bits are defined according to the table 12
- Kramer protocol 2000 13
- Caution 15
- Distributors visit our web site 15
- For the latest information on our products and a list of kramer 15
- Kramer electronics ltd 15
- Safety warning safety warning 15
- We welcome your questions comments and feedback 15
- Where updates to this user manual may be found 15
