TV Installation

Mounting the TV on a wall

If you mount this product on a wall, follow the instructions exactly as

recommended by the manufacturer. Unless it is correctly mounted, the

product may slide or fall, thus causing serious injury to a child or adult and

serious damage to the product.

Installing the wall mount kit

You can mount the TV on the wall using a wall mount kit (sold separately).

To mount both a soundbar and the TV onto a wall using the wall mount, mount the soundbar

onto the TV first, and then mount the TV/Soundbar combination onto the wall mount. For

detailed information, see the instructions provided with the soundbar.

- The soundbar installation with the wall mount may not be supported for the specific

region or model.

Wall

mount

Bracket

For detailed information about installing the wall mount, see the instructions provided with the

wall mount kit. We recommend that you contact a technician for assistance when installing

the wall mount bracket. We do not advise you to do it yourself. Samsung Electronics is not

responsible for any damage to the product or injury to yourself or others if you choose to

install the wall mount on your own.

VESA wall mount kit notes and specifications

You can install your wall mount on a solid wall perpendicular to the floor. Before attaching the

wall mount to surfaces other than plaster board, contact your nearest dealer for additional

information. If you install the TV on a ceiling or slanted wall, it may fall and result in severe

personal injury.

Product Family TV size in inches

VESA screw hole specs

(A * B) in millimetres

C (mm)

UHD-TV

[Curved]

40 200 x 200 18.1 ~ 20.5

Product Family Standard Screw Quantity

UHD-TV

[Curved]

M8 4
