Chapter 1
Getting Started
Overview
Status Indicators
1 2 3 4 5
1
Caps Lock
This turns on when the Caps Lock key is
pressed allowing capital letters to be typed
without holding the Shift button down.
On: Upper-case alphabetic input
O: Lower-case alphabetic input
2
HDD/ODD
This turns when either the HDD or ODD is
being accessed.
3
Wireless LAN
This turns on when the wireless LAN is
operating.
4 Charge Status
This shows the power source and the
battery charge status.
Green: When the battery is fully charged
or the battery is not installed.
Red: When the battery is being charged.
O: When the computer is running on
battery power without being connected
to AC adapter.
5 Power
This shows the computer operating status.
On: When the computer is operating.
Blinks: When the computer is in Sleep
mode.
