ASRock b85m-itx [31/80] A tuning
![ASRock b85m-itx [31/80] A tuning](/views2/1159403/page31/bg1f.png)
B85M-ITX
27
English
3.2 A-Tuning
A-Tuning is ASRock’s multi purpose soware suite with a new interface, more new
features and improved utilities, including XFast RAM, Dehumidier, Good Night
LED, FAN-Tastic Tuning, OC Tweaker and a whole lot more.
3.2.1 Installing A-Tuning
When you install the all-in-one driver to your system from ASRock’s support CD,
A-Tu ni ng will be auto-installed as well. Aer the installation, you will nd the icon
“A-Tu ni ng“ on your desktop. Double-click the “A-Tu ning“ icon, A-Tu ning
main menu will pop up.
3.2.2 Using A-Tuning
ere are ve sections in AXTU main menu: Operation Mode, Tools, OC Tweaker,
System Info and Tech Service.
Operation Mode
Choose an operation mode for your computer.
