11
English
Fatal1ty B85 Killer Series
1.5 I/O Panel
No. Description No. Description
1 Fatal1ty Mouse Port (USB0) 9 Microphone (Pink)
2 USB 2.0 Port (USB1) 10 Optical SPDIF Out Port
3 D-Sub Port 11 USB 2.0 Ports (USB23)
4 LAN RJ-45 Port* 12 USB 3.0 Ports (USB3_0_1)
5 Central / Bass (Orange) 13 HDMI Port
6 Rear Speaker (Black) 14 DVI-D Port
7 Line In (Light Blue) 15 PS/2 Mouse/Keyboard Port
8 Front Speaker (Lime)**
1 3 4 6
91015 11121314
5
2
1 7
8
