Fatal1ty H97 Performance Series
7
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 Power Fan Connector (PWR_FAN1)
3 CPU Fan Connector (CPU_FAN2)
4 CPU Fan Connector (CPU_FAN1)
5 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
6 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
7 ATX Power Connector (ATXPWR1)
8 USB 3.0 Header (USB3_4_5)
9 SATA3 Connector (SATA3_2)
10 SATA3 Connector (SATA3_5)
11 SATA3 Connector (SATA3_4)
12 SATA3 Connector (SATA3_1)
13 Chassis Fan Connector (CHA_FAN1)
14 SATA3 Connector (SATA3_3)
15 SATA3 Connector (SATA3_0)
16 USB 2.0 Header (USB4_5)
17 USB 2.0 Header (USB6_7)
18 Power LED Header (PLED1)
19 System Panel Header (PANEL1)
20 Chassis Speaker Header (SPEAKER1)
21 COM Port Header (COM1)
22 Front Panel Audio Header (HD_AUDIO1)
23 underbolt AIC Connector (TB1)
24 BIOS Selection Jumper (BIOS_SEL1)
25 Clear CMOS Jumper (CLRCMOS1)
26 PCIe Power Connector (PCIE_PWR1)
27 TPM Header (TPMS1)
28 Chassis Fan Connector (CHA_FAN3)
29 Chassis Fan Connector (CHA_FAN2)
