![ASRock fm2a68m-dg3+ [6/65] Chipset](/views2/1159452/page6/bg6.png)
English
2
Platform
Micro ATX Form Factor
All Solid Capacitor design
High Density Glass Fabric PCB
CPU
Supports Socket FM2+ 95W / FM2 100W processors
Chipset
AMD A68H (Bolton-D2H)
Memory
Dual Channel DDR3 Memory Technology
2 x DDR3 DIMM Slots
Supports DDR3 2400+(OC)/2133(OC)/1866
(OC)/1600/1333/1066 non-ECC, un-buffered memory
(see CAUTION 1)
Max. capacity of system memory: 32GB
(see CAUTION 2)
Supports Intel
®
AMP 2400
Expan-
sion
Slot
1 x PCI Express 3.0 x16 Slot (PCIE1@ x16 mode)
* PCIE 3.0 is only supported with FM2+ CPU. With FM2
CPU, it only supports PCIE 2.0.
1 x PCI Express 2.0 x1 Slot
1 x PCI Slot
Supports AMD Dual Graphics
Graphics
Integrated AMD Radeon
TM
R7/R5 Series Graphics in
A-series APU
DirectX 11.1, Pixel Shader 5.0 with FM2+ CPU. DirectX
11, Pixel Shader 5.0 with FM2 CPU.
Max. shared memory 2GB
by independent display controllers
2560x1600 @ 60Hz
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
