7
English
Z170M Pro4S
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
5 ATX Power Connector (ATXPWR1)
6 SATA3 Connector (SATA3_0)
7 SATA3 Connector (SATA3_1)
8 USB 3.0 Header (USB3_5_6)
9 Chassis Fan Connector (CHA_FAN2)
10 SATA3 Connector (SATA3_2)
11 SATA3 Connector (SATA3_3)
12 SATA3 Connector (SATA3_5)
13 SATA3 Connector (SATA3_4)
14 System Panel Header (PANEL1)
15 Chassis Intrusion and Speaker Header (SPK_CI1)
16 Clear CMOS Jumper (CLRMOS1)
17 USB 2.0 Header (USB1_2)
18 TPM Header (TPMS1)
19 COM Port Header (COM1)
20 Front Panel Audio Header (HD_AUDIO1)
21 Chassis Fan Connector (CHA_FAN1)
