![ASRock fatal1ty z170 gaming k4 [10/97] Expansion slot](/img/pdf.png)
ASRock fatal1ty z170 gaming k4 [10/97] Expansion slot
![ASRock fatal1ty z170 gaming k4 [10/97] Expansion slot](/views2/1159555/page10/bga.png)
2 3
English
1.2 Specications
Platform
• ATX Form Factor
• High Density Glass Fabric PCB
CPU
• Supports 6
th
Generation Intel® Core
TM
i7/i5/i3/Pentium®/
Celeron® Processors (Socket 1151)
• Digi Power design
• 10 Power Phase design
• Supports Intel® Turbo Boost 2.0 Technology
• Supports Intel® K-Series unlocked CPUs
• Supports ASRock BCLK Full-range Overclocking
Chipset
• Intel
®
Z170
Memory
• Dual Channel DDR4 Memory Technology
• 4 x DDR4 DIMM Slots
• Supports DDR4 3866+(OC)*/3600(OC)/3200(OC)/2933(OC)
/2800(OC)/2400(OC)/2133 non-ECC, un-buered memory
* 3866+(OC) memory frequency can only be achieved when a
single memory module is installed (Single channel memory).
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
• Max. capacity of system memory: 64GB
• Supports Intel® Extreme Memory Prole (XMP) 2.0
• 15μ Gold Contact in DIMM Slots
Expansion
Slot
• 2 x PCI Express 3.0 x16 Slots (PCIE2: x16 mode; PCIE4: x4
mode)
• 3 x PCI Express 3.0 x1 Slots (Flexible PCIe)
• Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
• 15μ Gold Contact in VGA PCIe Slot (PCIE2)
Graphics
* Intel® HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU integrated.
