4
English
Wireless
LAN
•
Supports IEEE 802.11a/b/g/n/ac
•
Supports Dual-Band (2.4/5 GHz)
•
Supports high speed wireless connections up to 867Mbps
•
2 antennas to support 2 (Transmit) x 2 (Receive) diversity
technology
•
Supports Bluetooth 4.0 / 3.0 + High speed class II
Rear Panel
I/O
•
1 x PS/2 Mouse/Keyboard Port
•
2 x HDMI Ports
•
1 x DisplayPort 1.2
•
1 x Optical SPDIF Out Port
•
1 x USB 3.1 Type-A Port (10 Gb/s) (ASMedia ASM1142)
(Supports ESD Protection (ASRock Full Spike Protection))
•
1 x USB 3.1 Type-C Port (10 Gb/s) (ASMedia ASM1142)
(Supports ESD Protection (ASRock Full Spike Protection))
•
5 x USB 3.0 Ports (Intel® Z170) (Supports ESD Protection
(ASRock Full Spike Protection))
•
1 x Fatal1ty Mouse Port (USB 3.0) (Supports ESD Protection
(ASRock Full Spike Protection))
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
1 x Clear CMOS Switch
•
HD Audio Jacks: Line in / Front Speaker / Microphone
Storage
•
6 x SATA3 6.0 Gb/s Connectors by Intel® Z170, support
RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid
Storage Technology 14 and Intel Smart Response
Technology), NCQ, AHCI and Hot Plug
•
1 x SATA Express 10 Gb/s Connector*
* Support to be announced
* If M2_1 is occupied by a SATA-type M.2 device, SATA3_0,
SATA3_1 and the SATA function of SATA_EXP0 will be dis-
abled.
•
1 x Ultra M.2 Socket, supports M.2 SATA3 6.0 Gb/s module
and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
