![ASRock 960GM-GS3 FX [36/55] Bios setup utility](/img/pdf.png)
ASRock 960GM-GS3 FX [36/55] Bios setup utility
![ASRock 960GM-GS3 FX [36/55] Bios setup utility](/views2/1159612/page36/bg24.png)
3636
3636
36
3.33.3
3.33.3
3.3
OC TOC T
OC TOC T
OC T
weakweak
weakweak
weak
er Screener Screen
er Screener Screen
er Screen
In the OC Tweaker screen, you can set up overclocking features.
BIOS SETUP UTILITY
Main
Advanced H/W Monitor Boot Security Exit
Overclocking may cause
damage to your CPU and
motherboard.
It should be done at
your own risk and
expense.
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
EZ Overclocking
Load Optimized CPU OC Setting [Press Enter]
CPU Configuration
CPU Frequency (MHz)
PCIE Frequency (MHz)
Overclock Mode
[200]
[100]
[Auto]
Spread Spectrum
Boot Failure Guard
Advanced Clock Calibration
CPU Active Core Control
Boot Failure Guard Count
AMD Turbo Core Technology
AMD IO C-State Support
Processor Maximum Frequency
North Bridge
Processor Maximum Voltage
Maximum Frequency
x13.5 2700 MHZ
x10.0 20
1.325 V
00 MHz
[Auto]
[Enabled]
[3]
[Disabled]
[Disabled]
[Auto]
[Enabled]
Multiplier/Voltage Change
[Auto]
Load Optimized mGPU OC Setting [Press Enter]
EZ Overclocking
Load Optimized CPU OC Setting
You can use this option to load the optiomized CPU overclocking setting.
Please note that overclocking may cause damage to your CPU and
motherboard. It should be done at your own risk and expense.
960GM-S3 FX
System Time [Hour:Minute:Second]
Use this item to specify the system time.
System Date [Day Month/Date/Year]
Use this item to specify the system date.
BIOS SETUP UTILITY
Main
OC Tweaker H/W Monitor Boot Security ExitAdvanced
Use [Enter], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Time.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
System Overview
System Time
System Date
[ :00:09]
[Tue 09/13/2011]
BIOS Version
Processor Type
Processor Speed
Microcode Update
L1 Cache Size
L2 Cache Size
Total Memory
DDR3_A1
DDR3_B1
: 960GM-S3 FX P1.0
: AMD Athlon(tm) II X2 235e
Processor (64bit)
: 2700MHz
: 100F62/10000C7
: 256KB
: 2048KB
: 1024MB with 128MB shared memory
Single-Channel Memory Mode
: 1024MB/800MHz DDR3_1600
: None
