![Asus tuf vanguard b85 [20/86] Ddr3 1600 mhz capability](/img/pdf.png)
Asus tuf vanguard b85 [20/86] Ddr3 1600 mhz capability
![Asus tuf vanguard b85 [20/86] Ddr3 1600 mhz capability](/views2/1159643/page20/bg14.png)
1-10
Chapter 1: Product introduction
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip No. Timing Voltage
DIMM socket
support (Optional)
2 DIMMs 4 DIMMs
CORSAIR
CMZ32GX3M4X1600C10
(Ver2.2)(XMP)
32GB ( 4x 8GB ) DS - - 10-10-10-27 1.5 • •
CORSAIR
CMZ4GX3M1A1600C9 (
Ver8.16)(XMP)
4GB ( 1x 4GB ) DS - - 9-9-9-24 1.5 •
CORSAIR
CMZ8GX3M1A1600C10
(Ver3.23)(XMP)
8GB ( 1x 8GB ) DS - - 10-10-10-27 1.5 •
CORSAIR
CMZ8GX3M1A1600C10
(Ver8.21)(XMP)
8GB ( 1x 8GB ) DS - - 10-10-10-27 1.5 •
CORSAIR CMZ8GX3M2A1600C8(XMP) 8GB ( 2x 4GB ) DS - - 8-8-8-24 1.5 • •
CORSAIR
CMZ8GX3M2A1600C9
(Ver8.16)(XMP)
8GB ( 2x 4GB ) DS - - 9-9-9-24 1.5 •
CORSAIR CMZ8GX3M2A1600C9(XMP) 8GB ( 2x 4GB ) DS - - 9-9-9-24 1.5 •
Crucial
BLT4G3D1608DT1
TX0.16FM(XMP)
4GB DS - - 8-8-8-24 1.5 • •
Elixir M2X2G64CB88G7N-DG(XMP) 2GB SS Elixir
N2CB2G80
GN-DG
9-9-9-28 - • •
Elixir M2X4G64CB8HG5N-DG(XMP) 4GB DS Elixir
N2CB2G8
0GN-DG
9-9-9-28 - • •
G.SKILL F3-12800CL9D-8GBSR2(XMP) 8GB ( 2x 4GB ) DS - - 9-9-9-24 1.25 • •
G.SKILL F3-12800CL9Q-16GBXL(XMP) 16GB ( 4x 4GB ) DS - - 9-9-9-24 1.5 • •
G.Skill F3-12800CL9Q-16GBZL(XMP) 16GB ( 4x 4GB ) DS - - 9-9-9-24 1.5 • •
G.SKILL F3-1600C9Q-32GXM(XMP) 32GB ( 4x 8GB ) DS - - - 1.5 • •
GEIL GUP34GB1600C7DC(XMP) 4GB ( 2x 2GB ) DS - - 7-7-7-24 1.6 • •
GEIL GVP38GB1600C8QC(XMP) 8GB ( 4x 2GB ) DS - - 8-8-8-28 1.6 •
Hynix HMT351U6CFR8C-PB 4GB DS Hynix H5TQ2G83CFR - - •
Hynix HMT41GU6MFR8C-PB 8GB DS Hynix H5TQ4G83MFR - - •
KINGMAX FLGE85F-C8KL9A(XMP) 2GB SS
KING
MAX
N/A 9-9-9-28 - • •
KINGMAX FLGF65F-C8KL9A(XMP) 4GB DS
KING
MAX
N/A 9-9-9-28 - • •
KINGSTON KHX16009CD3K2/8GX(XMP) 8GB ( 2x 4GB ) DS - - 9-9-9-27 1.65 • •
KINGSTON KHX1600C9D3B1/4G(XMP) 4GB SS - - 9-9-9-27 1.65 • •
KINGSTON KHX1600C9D3K3/12GX(XMP) 12GB ( 3x 4GB ) DS - - 9 1.65 •
KINGSTON KHX1600C9D3K3/6GX(XMP) 6GB ( 3x 2GB ) DS - - 9 1.65 • •
KINGSTON KHX1600C9D3K3/6GX(XMP) 6GB ( 3x 2GB ) DS - - 9 1.65 • •
KINGSTON KHX1600C9D3K4/16GX(XMP) 16GB ( 4x 4GB ) DS - - 9-9-9-24 1.65 • •
KINGSTON KHX1600C9D3K6/24GX(XMP) 24GB ( 6x 4GB ) DS - - 9 1.65 • •
KINGSTON KHX1600C9D3K8/32GX(XMP) 32GB ( 8x 4GB ) DS - - 9-9-9-27 1.65 • •
KINGSTON KHX1600C9D3LK2/8GX(XMP) 8GB ( 2x 4GB ) DS - - 9-9-9-24 1.35 • •
KINGSTON KHX1600C9D3P1K2/8G 8GB ( 2x 4GB ) DS - - 9 1.5 • •
KINGSTON KHX16C10B1K2/16X(XMP) 16GB ( 2x 8GB ) DS - - - 1.5 • •
KINGSTON KHX16C9K2/16 16GB ( 2x 8GB ) DS - -
1333-9-
9-9-24
1.5 • •
KINGSTON KHX16C9P1K2/16 16GB ( 2x 8GB ) DS - - - 1.5 • •
KINGSTON KVR16N11/4 4GB DS
KINGS
TON
D2568JPU
CPGGBU
11-11-11
-28-1
- • •
KINGSTON KVR16N11/4 4G DS Hynix
H5TQ2G83
CFRPBC
- 1.5 • •
MICRON MT16JTF1G64AZ-1G6D1 8GB DS
MIC
RON
D9PBC - 1.5 • •
Micron MT16JTF1G64AZ-1G6E1 8GB DS Micron D9QBJ - - • •
MICRON MT16KTF51264AZ-1G6M1 4GB DS
MIC
RON
D9PFJ 11-11-11-28 - •
MICRON MT16KTF51264AZ-1G6M1 4GB DS
MIC
RON
D9PFJ - - • •
Micron MT8JTF51264AZ-1G6E1 4GB SS Micron D9QBJ - - • •
MICRON MT8KTF25664AZ-1G6M1 2GB SS
MICR
ON
D9PFJ - - • •
Patriot PGD316G1600ELK(XMP) 16GB ( 2x 8GB ) DS - - - 1.65 • •
Patriot PGD316G1600ELK(XMP) 16GB ( 2x 8GB ) DS - - 9-9-9-24 1.5 •
Patriot PGD38G1600ELK(XMP) 8GB ( 2x 4GB ) DS - - 9-9-9-24 1.65 • •
Patriot PGD38G1600ELK(XMP) 8GB ( 2x 4GB ) DS - - 9-9-9-24 1.5 •
Patriot PV316G160C9QKRD(XMP) 16GB ( 4x 4GB ) DS - - 9-9-9-24 1.5 •
Patriot PV38G160C9KRD(XMP) 8GB ( 2x 4GB ) DS - - 9-9-9-24 1.5 • •
Patriot PVV38G1600LLK(XMP) 8GB ( 2x 4GB ) DS - - 8-9-8-24 1.65 • •
Patriot PX538G1600LLK(XMP) 8GB ( 2x 4GB ) DS - - 8-9-8-24 1.65 •
Patriot PX7312G1600LLK(XMP) 12GB ( 3x 4GB ) DS - - 8-9-8-24 1.65 • •
Patriot PXD38G1600LLK(XMP) 8GB ( 2x 4GB ) DS - -
1600 8-
9-8-24
1.65 • •
PSC AL9F8L93B-GN2E 4GB SS PSC A3P4GF3BLF - - • •
PSC ALAF8L93B-GN2E 8GB DS PSC A3P4GF3BLF - - • •
DDR3 1600 MHz capability
continued on the next page
