ASUS MAXIMUS VI HERO
4-5
Chapter 4
Click to launch AI Suite 3 menu bar
The Ai Suite 3 screenshots in this section are for reference only and can vary depending on
motherboard model.
AI Suite 3 Main menu
The AI Suite 3 main menu gives you easy-access controls and insight to what’s going on
with your computer - allowing you to optimize performance settings while at the same time
ensuring system stability.
Included in the AI Suite 3 main menu is a quick-access menu bar that allows you to swiftly
launch any of the integrated ASUS utilities. Click or tap the on the top-edge of menu to
launch the menu bar.
AI Suite 3 main menu bar
• Some functions in the AI Suite 3 main menu in this user manual may vary depending
on the motherboard model.
• Refer to the software manual in the support DVD or visit the ASUS website atRefer to the software manual in the support DVD or visit the ASUS website at
www.asus.com for detailed software conguration.
System
Information
USB Charger+
Ai Charger+
EZ Update
USB BIOS
Flashback
4-Way Optimization
USB 3.0 Boost
