Smeg P106 [13/14] Burner lighting with safety device

Instructions for the user

7. Using the hob

Check that the flame cap crowns, the burner caps and grids

are correctly assembled.

Pins A of the flame cap crowns must be inserted in housings

B of the burner rings, and pins C on the grids must be

blocked in their respective housings on the hob.

7.1 Burner lighting with safety device

Each knob shows the burner it is for (the example at the side corresponds to the front

left burner).

The appliance is equipped with an electronic lighter. Just press and simultaneously

turn the knob anticlockwise to the minimum flame symbol until the burner lights.

Keep the knob pressed down for about 2 seconds to keep the flame alight and

activate the safety device. It may happen that the burner goes out when the knob is

released. In this case, repeat the operation, keeping the knob pressed down for a

longer time.

If the burners should go out accidentally, after a roughly 20 second interval the safety

device intervenes to block gas flow, including when the tap is open.

7.2 Practical advice for using the burners

For better burner performance and minimum gas consumption, flat

bottomed, even recipients must be used, with covers and

proportional in size to the burners (see paragraph “7.3 Diameter of

containers ”).

To avoid overcooking or damage to the surface top while cooking, all

recipients or griddles must be positioned within the cooking hob

perimeter and must be a minimum distance of 3-4 cm from the

knobs.

7.3 Diameter of containers

BURNERS

1 Auxiliary

2 Semi rapid

3 Medium rapid

4 Large rapid

5 UR

Ø min. and max. (in cm)

7-18

10-24

18-24

20-24

20-28
