Internal Connectors
1 x USB 3.0 connector (supports additional two USB 3.0 ports)
3 x USB 2.0 connectors (support additional six USB 2.0 ports, two
connectors share with ROG_EXT header)
1 x ROG Extension (ROG_EXT) header
8 x SATA 6Gb/s connectors
1 x 4-pin CPU fan connector
1 x 4-pin CPU optional fan connector
3 x 4-pin Chassis fan connectors
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V Power connector
1 x Clear CMOS button
1 x Power-on button
1 x Reset button
1 x MemOK! button
1 x Slow mode
1 x LN2 mode
1 x DRCT header
1 x Front panel audio connector (AAFP)
1 x System panel connector
7 x ProbeIt measurement points
1 x TPM connector
1 x Sonic SoundStage button
1 x KeyBot button
BIOS Features
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.7, WfM 2.0, SM
BIOS 2.7, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS
CrashFree BIOS 3, My Favorites, Quick Note, Last Modied log,
F12 PrintScreen, F3 Shortcut functions, and ASUS DRAM SPD
(Serial Presence Detect) memory information
Operating System
Windows
®
8.1
Windows
®
8
Windows
®
7
Software
Drivers
ROG GameFirst III
ROG RAMDisk
ROG CPU-Z
Kaspersky
®
Anti-Virus
DAEMON Tools Pro Standard
ASUS WebStorage
Home Cloud
ASUS Utilities
Form Factor
ATX Form Factor, 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Specications are subject to change without notice.
CROSSBLADE RANGER specifications summary
