Telefunken TF-1567U [7/15] Instruction manual

Instruction manual

Specifications

FM frequency range 64 - 108 MHz

Nominal voltage (clock) 3 V (1.5 V x 2 batteries AG13)

Nominal voltage 6 V

Nominal power consumption 5.4 W

Output power 2 x 2 W

Adaptor input power 220 V ~ 50 Hz

Adaptor output power 6 V (DC)/600 mA

Supported storages USB/SD/MMC

Net/Gross weight 0.86 kg/1.13 kg

Unit dimensions 250 mm x 100 mm x 100 mm

Due to continuous improvement of the device, the specifications and functions in the manual

are subject to change without notice.

Troubleshooting guide

Below is a table describing simple measures of eliminating most problems that can emerge

while using this unit. If the below measures do not help, turn to the neares service center or

dealer.

Trouble Cause Solution

Low quality of FM signal reception. The telescopic antenna is

not extended.

Extend and adjust the

position of the antenna.

Time and date settings are reset after

power outage

AG13 batteries are

absent, inserted

incorrectly or discharged.

Insert AG13 batteries

with correct polarity.

Replace discharged

batteries.

ATTENTION: AG13 batteries are consumables not covered by warranty, and their failure

(discharge) is not a ground for addressing to service and repair centers.
