![Asus rog maximus vii impact [30/238] Chapter 1](/views2/1160775/page30/bg1e.png)
1-14
Chapter 1: Product introduction
Chapter 1
DDR3 2666 MHz capacity
Vendors Part No. Size SS/DS Chip
Brand
Chip
NO.
Timing Voltage DIMM socket
support
(Optional)
2
Apacer 78.BAGFF.AFC0C(XMP) 8GB (2x4GB) DS - - 12-13-13-35 - •
Apacer 78.BAGFR.AFD0C(XMP) 8GB (2x4GB) DS - - 12-13-13-35 - •
Apacer 78.CAGFF.AFD0C(XMP) 16GB (2x8GB) DS - - 12-13-13-35 - •
CORSAIR CMD16GX3M4A2666C11
(Ver5.12)(XMP)
16GB (4x4GB) DS - - 11-13-13-35 1.65 •
G.SKILL F3-2666CL10Q-
16GBZHD(XMP)
16GB (4x4GB) DS - - 10-12-12-31 1.65 •
GeIL GOC332GB2666C11QC(XMP) 32GB (4x8GB) DS - - 11-13-13-32 1.65 •
Kingston KHX26C11T2K2/8X(XMP) 8GB (2x4GB) SS - - 2666-11-13-
13-32
1.65 •
DDR3 2400 MHz capacity
Vendors Part No. Size SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage DIMM socket
support
(Optional)
2
ADATA AX3U2400W4G11-DMV(XMP) 8GB (2x4GB) SS - - 11-13-13-35 1.65 •
ADATA AX3U2400W8G11-DMV(XMP) 16GB (2x8GB) DS - - 11-13-13-35 1.65 •
Apacer 78.BAGFL.AFD0C(XMP) 8GB (2x4GB) DS - - 11-12-12-30 - •
Apacer 783BAGF3.AFD0C(XMP) 8GB (2x4GB) DS - - 11-11-11-30 - •
CORSAIR CMD16GX3M2A2400C10
(Ver4.21)(XMP)
16GB (2x8GB) DS - - 10-12-12-31 1.65 •
CORSAIR CMD32GX3M4A2400C10
(Ver5.29)(XMP)
32GB (4x8GB) DS - - 10-12-12-31 1.65 •
CORSAIR CMD32GX3M4A2400C10(Ver
4.21)(XMP)
32GB (4x8GB) DS - - 10-12-12-31 1.65 •
CORSAIR CMY16GX3M2A2400C10A
(Ver4.21)(XMP)
16GB (8x2GB) DS - - 10-12-12-31 1.65 •
CORSAIR CMY16GX3M2A2400C10R
(Ver4.21)(XMP)
16GB (2x8GB) DS - - 10-12-12-31 1.65 •
CORSAIR CMZ16GX3M2A2400C10
(Ver4.21)
16GB (2x8GB) DS - - 10-12-12-31 1.65 •
G.SKILL F3-19200CL10Q2-
64GBZHD(XMP)
64GB (8x8GB) DS - - 10-12-12-31 1.65 •
G.SKILL F3-19200CL10Q-32GBZHD(XMP) 32GB (4x8GB) DS - - 10-12-12-31 1.65 •
G.SKILL F3-19200CL11Q-16GBZHD(XMP) 16GB (4x4GB) DS - - 11-11-11-31 1.65 •
G.SKILL F3-19200CL9D-4GBPIS(XMP) 4G (2x2GB) DS - - 9-11-9-28 1.65 •
G.SKILL F3-19200CL9Q-16GBZMD(XMP) 16GB (4x4GB) DS - - 9-11-11-31 1.65 •
G.SKILL F3-2400C11Q-32GXM(XMP) 32GB (4x8GB) DS - - 11-13-13-31 1.65 •
GeIL GOC316GB2400C10QC(XMP) 16GB (4x4GB) DS - - 10-11-11-30 1.65 •
GeIL GOC316GB2400C11QC(XMP) 16GB (4x4GB) DS - - 11-11-11-30 1.65 •
Kingston KHX2400C11D3K4/8GX(XMP) 8GB (4x2GB) SS - - 11-13-11-30 1.65 •
(Continued on the next page)
