![Viewsonic P70f [12/20] Specifications](/views2/1161656/page12/bgc.png)
ViewSonic P70f 11
Other Information
1
Macintosh models prior to G3 require a Macintosh adapter. To order a ViewSonic Macintosh adapter,
contact Customer Support. You will need to provide the product serial number.
NOTE: This product was designed for operation in the magnetic fields of the hemisphere where it was
purchased.
Specifications
CRT
Ty pe
Phosphor
Glass surface
17" (16.0" viewable diagonal area), 0.24 mm stripe
pitch, PerfectFlat
®
, 90° deflection
RGB medium/short persistence
TM = 40%, anti-static, anti-reflection
Input Signal
Video
Sync
RGB Analog (0.7Vp-p, 75 Ohms)
f
H
: 30-97 kHz, f
v
: 50-180 Hz
HV Separate (TTL)
Compatibility
PC
Macintosh
1
VGA up to 1920 x 1440
Power Macintosh
®
G3, G4 (from 640 x 480 to
1920 x 1440; may require Macintosh cable adapter)
Resolution
Recommended and
supported
1600 x 1200 @ 75 Hz (VESA)
1280 x 1024 @ 75, 85 Hz (VESA)
1024 x 768 @ 75, 85 Hz (VESA)
800 x 600 @ 85 Hz (VESA)
640 x 480 @ 60, 85 Hz (VESA)
640 x 400 @ 70 Hz (VGA)
832 x 624 @ 75 Hz (Mac)
1024 x 768 @ 74.9 Hz (Mac)
640 x 480 @ 66.7 Hz (Mac)
Power
Voltage AC 90-260 VAC (auto switch)
50/60 (+/- 3)Hz
Display Area
Default
Full scan
310 mm (H) x 232 mm (V) (typical)
325 mm (H) x 244 mm (V) (depends on signal timing)
Operating
Conditions
Temperature
Humidity
Altitude
+32° F to +104° F (0° C to +40° C)
5% to 95% (no condensation)
To 10,000 feet
Storage
Conditions
Temperature
Humidity
Altitude
-40° F to +140° F (-40° C to +60° C)
5% to 95% (no condensation)
To 40,000 feet
Dimensions
Physical
(monitor)
422 mm (W) x 433 mm (H) x 431 mm (D)
16.63” (W) x 17.04” (H) x 16.95” (D)
Weight
Net (monitor only) 17.1 kg (37.62 lb)
Regulations
UL, cUL, CSA, FCC-B, CB, ISO9241-3, CE, DHHS,
DOC-B, MPR-II, NOM, IRAM, TUV/GS, VCCI, BSMI,
PSB, C-Tick, S. Africa, TUV/Ergo, NEMKO, SEMKO,
DEMKO, FIMKO, PCBC, GOST, SASO, CCIB,
CCEE, EMC, KMI-B, TCO 99, Energy Star
®
Power Saving
Modes
On
Off
< 120 W Maximum (Green LED)
< 3 W (Orange LED)
