Содержание

E8682 revised edition v2 september 2013 2
Chapter 1 product introduction 3
Chapter 2 hardware setup 3
Contents 3
Chapter 3 rackmount installation 4
Chapter 4 motherboard info 4
Chapter 5 bios setup 4
Contents 4
Chapter6 raidconfiguration 5
Contents 5
Chapter 7 driver installation 6
Contents 6
Australia statement notice 7
Canadian department of communications statement 7
Federal communications commission statement 7
Notices 7
Class 1 laser product 8
Electrical safety 8
Operation safety 8
Safety information 8
About this guide 9
Audience 9
Contents 9
Bold text indicates a menu or an item to select 10
Command means that you must type the command exactly as shown then supply the required item or value enclosed in brackets 10
Conventions 10
Example at the dos prompt type the command line format a s 10
If you must press two or more keys simultaneously the key names are linked with a plus sign 10
Means that you must press the enter or return key 10
References 10
Typography 10
Chapter 1 11
Product overview 11
Serial number label 12
System package contents 12
Systemspecifications 13
Asus rs100 e8 pi2 15
Front panel features 15
Rear panel features 15
Refer to section 1 front panel leds for the led descriptions 15
The ports for the ps 2 mouse keyboard combo usb 2 usb 3 vga com port and gigabit lan do not appear on the rear panel if the motherboard is not installed 15
The rear panel has the ac power socket and access to any added expansion cards the i o shield with openings for the rear panel connectors on the motherboard are also found in the rear panel 15
This barebone server has a simple yet stylish front panel with easily accessible features the power and reset buttons led indicators optical drive and two usb ports are located on the front panel 15
This port is for an asus asmb7 ikvm controller card only 15
Turn off the system power and detach the power supply before removing or replacing any system component 15
Internal features 16
Front panel leds 17
Led information 17
Lan rj 45 leds 18
Chapter 2 19
Hardware setup 19
Chapter 2 hardware setup 20
Chassis cover 20
Firmly hold the cover and slide it toward the rear panel for about half an inch until it is disengaged from the chassis 20
Lift the cover from the chassis 20
Removing the chassis cover 20
To remove the chassis cover 20
Use a phillips screwdriver to remove the three screws on the chassis cover 20
Reinstalling the chassis cover 21
Asus rs100 e8 pi2 23
Central processing unit cpu 23
E3 1200 v3 23
Installing the cpu 23
Locate the cpu socket on the motherboard 23
This server motherboard comes with a surface mount lga1150 socket designed for the inte 23
To install the cpu 23
Installing the cpu heatsink 26
Memoryconfigurations 28
Overview 28
System memory 28
Installing a dimm on a single clip dimm socket 29
Removing a dimm from a single clip dimm socket 30
Hard disk drives 31
Installing a 3 inch serial ata hdd to hdd bay 1 31
Installing 2 inch ssds on hdd bay 1 optional 33
Installing a hard disk drive to the hdd bay 2 36
Expansion card 39
Installing an expansion card 39
Configuringanexpansioncard 41
Standard interrupt assignments 41
Cable connections 42
Standard cables connected to the motherboard 42
Chassis fans 43
Removable optional components 43
Optical disk drive odd 44
Installing asmb7 series management card optional 45
Chapter 3 47
Rackmount installation 47
Attaching the rails to the rack 48
Rackmount rail kit items 48
Chapter 4 53
Motherboard info 53
Layout contents 55
Onboard leds 57
Jumpers 59
Connectors 62
Lan port led indications 62
Rear panel connectors 62
Internal connectors 63
4 pin frnt_fan1 rear_fan1 cpu_fan1 frnt_fan2 frnt_fan3 65
Asus rs100 e8 pi2 65
Cpu front and rear fan connectors 65
The fan connectors support cooling fans connect the fan cables to the fan connectors on the motherboard ensuring that the black wire of each cable matches the ground pin of the connector 65
4 pin power connector 4 pin pwr3 68
Atx power connectors 24 pin eatxpwr1 8 pin eatx12v1 68
Chapter 4 motherboard information 68
These connectors are for the atx power supply plugs the power supply plugs are designed to fit these connectors in only one orientation find the proper orientation and push down firmly until the connectors completely fit 68
This 4 pin connector provides 5v to an installed sata dom disk on module you can also use this 4 pin connector to connect to the psu to increase power by 12v 68
Bios setup 71
Chapter 5 71
Asus crashfree bios 3 utility 72
Managing and updating your bios 72
Recoveringthebiosfromausbflashdrive 72
Asus easy flash utility 73
Bupdater utility 74
Updatingthebiosfile 74
Asus rs100 e8 pi2 75
Do not shut down or reset the system while updating the bios to prevent system boot failure 75
Reboot the system from the hard disk drive 75
The bios update is finished please restart your system 75
The utility returns to the dos prompt after the bios update process is completed 75
The utility verifies the file then starts updating the bios file 75
Writing bios 75
Bios setup program 76
Advanced for changing the advanced system settings 77
Asus rs100 e8 pi2 77
Bios menu screen 77
Boot for changing the system boot configuration 77
Event logs for changing the event log settings 77
Exit for selecting the exit options 77
Main for changing the basic system configuration 77
Menu bar 77
Monitor for displaying the system temperature power status and changing the fan settings 77
Security for changing the security settings 77
The menu bar on top of the screen has the following main items 77
To select an item on the menu bar press the right or left arrow key on the keyboard until the desired item is highlighted 77
Tool for configuring options for special functions 77
Configurationfields 78
General help 78
Menu items 78
Navigation keys 78
Pop up window 78
Scroll bar 78
Submenu items 78
Main menu 79
System date 79
System time 79
Advanced menu 80
Chapter 5 bios setup 80
Take caution when changing the settings of the advanced menu items incorrect field values can cause the system to malfunction 80
The advanced menu items allow you to change the settings for the cpu and other hardware components 80
Asus rs100 e8 pi2 81
Cpuconfiguration 81
Navigate to the second page of the screen to see all of the items in this menu by pressing the up or down arrow keys 81
The items in this menu show cpu related information that the bios automatically detects some items may not appear if your cpu does not support the feature 81
To quickly go to the last item of the second page press the page down button press the page up button to go back to the first item in the first page 81
Active processor cores all 82
Adjacentcachelineprefetchenabled 82
Boot performance mode turbo performance 82
Cpu aes enabled 82
Eist enabled 82
Energy performance performance 82
Execute disable bit enabled 82
Hardware prefetcher enabled 82
Hyper threading enabled 82
Overclocking lock disabled 82
Turbo mode enabled 82
Virtualization technology enabled 82
Cpu c states enabled 83
Acpi t state enabled 84
Cfg lock enabled 84
Intel txt lt suppot disabled 84
Laketiny feature disabled 84
Package c state limit auto 84
Allows you to configure pch parameters 85
Allows you to control the disabling of the usb ports 0 13 85
Allows you to control the usb ehci usb 2 functions one ehci controller must always be enabled configuration options disabled enabled 85
Allows you to enable or disable trunk clock gating configuration options enabled disabled 85
Allows you to set the mode of operation of the xhci controller configuration options auto enabled disabled 85
Allows you to set the usb configuration settings 85
Asus rs100 e8 pi2 85
Btcg disabled 85
Ehci1 ehci2 enabled 85
Pch ioconfiguration 85
These items only appear when you set the usb ports per port disable control to enabled 85
Usb port 0 13 disabled enabled this item allows you to enable disable each of the usb ports 0 13 configuration options disabled enabled 85
Usb ports per port disable control disabled 85
Usbconfiguration 85
Xhci mode auto 85
Chapter 5 bios setup 86
S m a r t status check enabled 86
Sata controller s enabled 86
Sata mode selection ahci 86
Sataconfiguration 86
Self monitoring analysis and reporting technology s m a r t is a monitor system when read write of your hard disk errors occur this feature allows the hard disk to report warning messages during the post configuration options enabled disabled 86
This allows you to choose how sata controller s should operate configuration options ahci ide raid 86
This allows you to enable or disable the sata device configuration options enabled disabled 86
While entering setup the bios automatically detects the presence of sata devices the sata port items show not present if no sata device is installed to the corresponding sata port 86
Asus rs100 e8 pi2 87
Bdat acpi table support disabled 87
Compatible mode disabled this item only appears when you set the sata mode selection to ide this item allow you to enable or disable the compatible mode configuration options disabled enabled 87
Enable nb crid disabled 87
Systemagent sa configuration 87
This allows you enable or disable nb crid workaround configuration options enabled disabled 87
This allows you enable or disable support for the bdat acpi table configuration options enabled disabled 87
This allows you enable or disable vt d function on mch configuration options enabled disabled 87
This allows you to change system agent parameters 87
This allows you to prioritize between onboard and offboard video hardware configuration options onboard offboard 87
Vga priority offboard 87
Vt d enabled 87
Chapter 5 bios setup 88
Gdxc support disabled 88
Memory frequency limiter auto 88
Memory remap enabled 88
Memory scrambler enabled 88
Memoryconfiguration 88
This allows you to change memory information settings 88
This allows you to enable or disable gdxc feature configuration options enabled disabled 88
This allows you to enable or disable memory remap above 4g configuration options enabled disabled 88
This allows you to enable or disable memory scrambler support configuration options enabled disabled 88
This allows you to set the memory frequency in mhz configuration options 1333 1600 88
Above 4g decoding disabled 89
Allows you to change the settings of the pci express devices 89
Allows you to configure pci x and pci express settings 89
Allows you to enable or disable the rt32 image loading configuration options disabledenabled 89
Aspm support disabled 89
Asus rs100 e8 pi2 89
Configuration options disabled disables asmp auto bios auto configure force l0s force all links to l0s state 89
Load rt32 image enabled 89
Pci express settings 89
Pci subsystem settings 89
This item allows you to enable or disable 64 bit processing above the 4g address space if your system supports 64 bit pci decoding configuration options disabledenabled 89
This item allows you to enable or disable support for active state power management aspm aspm is a power management protocol that is used to extend battey life 89
Allows you to enable or disable pcie slots configuration options disabledenabled 90
Allows you to perform pcie slot configurations 90
Chapter 5 bios setup 90
Pcie option rom 3 7 enabled 90
Pcieslotconfiguration 90
The usb devices item shows the auto detected values if no usb device is detected the item shows none 90
This area allows you to configure usb settings 90
Usbconfiguration 90
Device power up delay auto 91
Device reset time out 20 sec 91
Ehci hand off enabled 91
Legacy usb support enabled 91
Port 60 64 emulation enabled 91
Usb mass storage driver support enabled 91
Usb transfer time out 20 sec 91
Usb3 support enabled 91
Xhci hand off enabled 91
Acpi settings 92
Acpi sleep state both s1 and s3 available for os to choose from 92
Allows you to enable or disable bios support for security devices configuration options disabled enabled 92
Allows you to enable or disable hibernation features os s4 sleep state 92
Allows you to set the acpi sleep state configuration options suspend disabled 92
Both s1 and s3 available for os to choose from 92
Chapter 5 bios setup 92
Configuration options disabled enabled 92
Enable hibernation enabled 92
S1 only cpu stop clock s3 only suspend to ram 92
Security device support disabled 92
Nct6779dsuperioconfiguration 93
Serialport1 2configuration 93
Whea enabled 93
Whea support 93
Allows you to enable or disable the intel i210 lan function in the system configuration options enabled disabled 94
Allows you to launch the intel i210 lan oprom configuration options disabled pxe iscsi 94
Chapter 5 bios setup 94
Intel i210 lan1 lan2 enable enabled 94
Intel i210 lan1 lan2 oprom 94
Onboardlanconfiguration 94
Server platform services 94
Server platform services configured in the system 94
This area allows you to configure the onboard lan 94
This item displays information on the inte 94
Com1 com2 console redirection disabled enabled 95
Com1 com2 console redirection settings 95
Serial port console redirection 95
Allows you to configure advance power management apm settings 97
Allows you to enable or disable the runtime error logging support configuration options disabled enabled 97
Allows you to set the state the system will go to after an ac power loss configuration options power off power on last state 97
Asus rs100 e8 pi2 97
Bits per second 115200 this item only appears when you set the console redirection to enabled selects serial port transmission speed the speed must be matched on the other side long or noisy lines may require lower speeds configuration options 9600 19200 38400 57600 115200 97
Flow control none this item only appears when you set the console redirection to enabled allows you to set the flow control to prevent data loss from buffer overflow configuration options none hardware rts cts software xon xoff 97
Power on by pcie disabled 97
Restore ac power loss last state 97
Runtime error logging support 97
Runtime error logging support disabled 97
This allows you to enable or disable pcie devices for waking up the system configuration options disabled enabled 97
Chapter 5 bios setup 98
Enables or disables the network stack feature configuration options disabled enabled 98
Eup ready disabled 98
Intel rc drivers version detail 98
Ipv4 ipv6 pxe support enabled allows you to enable or disable the ipv4 ipv6 pxe boot option configuration options disabled enabled 98
Network stack 98
Network stack disabled 98
Power on by rtc disabled 98
Rc drivers 98
These items only appear when you set network stack to enabled 98
This item allows you to enable or disable rtc to generate a wake event when set to enabled the items rtc alarm date days and hour minute second become available allowing you to set specific values 98
This item allows you to switch off some power at s5 to get the system ready for eup requirement configuration options enabled disabled 98
This item displays the version string of the intel 98
Asus rs100 e8 pi2 99
Change smbios event log settings 99
Erase event log no this item only appears when smbios event log is set to enabled this item allows you to select the options for erasing smbios event log configuration options no yes next reset yes every reset 99
Event logs menu 99
Smbios event log enabled allows you to enable or disable all features of smbios event logging during boot configuration options disabled enabled 99
The event logs menu items allow you to change the event log settings and view system event logs 99
When log is full do nothing this item only appears when smbios event log is set to enabled this item allows you to select an action when the event logs are full configuration options do nothing erase immediately 99
Allows you to enable or disable the full screen logo display feature configuration options disabled enabled 100
Allows you to select the power on state for the numlock configuration options off on 100
Allows you to set the display mode for option rom configuration options force bios keep current 100
Boot menu 100
Bootup numlock state on 100
Chapter 5 bios setup 100
Full screen logo enabled 100
Gatea20 active upon request 100
Keys to specify the values 100
Option rom messages force bios 100
Set this item to enabled to use the asus mylogo2 feature 100
Setup prompt timeout xx 100
The items in boot menu allows you to change the options on how the system will boot 100
This item is useful when any rt code above 1mb is executed when set to upon request the ga20 can be disabled using bios services when set to always disabling of ga20 is not allowed configuration options upon request always 100
Boot device seeking endless pxe 101
Boot option priorities 101
Cd dvd rom drive bbs priorities network device bbs priorities hard drive bbs priorities 101
Int19 trap response immediate 101
Csm parameters 102
Allows you to configure the asus smart fan feature to adjust fan speed for a more efficient system operation configuration options low speed mode generic mode high speed mode full speed mode 103
Asus rs100 e8 pi2 103
Cpu mb1 tr1 temperature xxxºc xxxºf 103
Cpu_fan1 speed frnt_fan1 3 speed rear_fan1 speed xxxx rpm or ignore n a 103
Fan speed control generic mode 103
Monitor menu 103
The monitor menu displays system temperature power status and allows you to change fan settings 103
The onboard hardware monitor automatically detects and displays the cpu and motherboard component temperatures 103
The onboard hardware monitor automatically detects and displays the speed of cpu fans front fans and rear fan in rotations per minute rpm if the fan is not connected to the motherboard the field shows n a 103
The onboard hardware monitor automatically detects the voltage output through the onboard voltage regulators 103
Vcore1 voltage 12v 5v vddq 3vsb 3 v and vbat 103
Administrator password 104
Chapter 5 bios setup 104
Confirm the password when prompted 104
Security 104
This menu allows a new password to be created or a current password to be changed the menu also enables or disables the secure boot state and lets the user configure the system mode state 104
To change an administrator password 104
To set an administrator password 104
When prompted to create confirm the password 104
Secure boot control enabled 105
Secure boot menu 105
Secure boot mode standard 105
User password 105
Chapter 5 bios setup 106
Factory default key provisioning disabled configuration options disabled enabled 106
Image execution policy 106
Install all factory default keys this item will ask you if you want to install factory default secure variables select yes if you want to load the default secure variables otherwise select no 106
Internal fv always execute configuration options always execute 106
Key management 106
Option rom removable media fixed media deny execute configuration options always execute always deny allow execute defer execute deny execute query user 106
Platform key pk key exchange key database kek authorized signature database db forbidden signature database dbx configuration options set new delete append 106
This item only appears when you set the secure boot mode to custom this allows you to manage the image policy on security violation 106
This item only appears when you set the secure boot mode to custom this allows you to modify secure boot variables and set key management page 106
A confirmation window appears select yes to discard changes and exit 107
A confirmation window appears select yes to save changes and exit 107
Allows you to run the start ezflash utility for more information see section asus ezflash utility 107
Asus rs100 e8 pi2 107
Discard changes exit 107
Exit menu 107
Save changes reset 107
Start ezflash utility 107
The exit menu items allow you to save or discard your changes to the bios items 107
To display the submenu 107
Tool menu 107
Discard changes reset 108
Launchefishellfromfilesystemdevice 108
Restore defaults 108
Chapter 6 109
Raidconfiguration 109
Raiddefinitions 110
Setting up raid 110
Installing hard disk drives 111
Raidconfigurationutilities 111
Setting jumpers 111
Setting the raid mode in bios 111
Before you proceed ensure that you have installed the serial ata hard disk drives have set the correct jumper settings of the motherboard and have set the correct sata mode in the bios setup you can refer to sections 5 installing hard disk drives 5 setting jumpers and 5 setting the raid mode in bios for more information 112
Chapter 6 raid configuration 112
More than once to enter the main menu 112
Rapid storage technology enterprise option rom utility 112
Rapid storage technology enterprise option rom utility allows you to create raid 0 raid 1 raid 10 raid 1 0 and raid 5 set s from serial ata hard disk drives that are connected to the serial ata connectors supported by the southbridge 112
The inte 112
The navigation keys at the bottom of the screen allow you to move through the menus and select the menu options 112
The raid bios setup screens shown in this section are for reference only and may not exactly match the items on your screen 112
To display the utility main menu 112
To launch the inte 112
Turn on the system 112
Asus rs100 e8 pi2 113
Creating a raid set 113
To create a raid set 113
To select the hard disk drives that you want to include in the raid set 113
When you are done 113
Asus rs100 e8 pi2 115
Deleting a raid set 115
Take caution when deleting a raid set you will lose all data on the hard disk drives when you delete a raid set 115
To delete a raid set 115
To return to the delete volume menu 115
Resetting disks to non raid 116
Exiting the inte 117
Rapid storage technology enterprise sata option rom utility 117
Rebuilding the raid 117
Rebuilding the raid with another non raid disk 117
Rebuilding the raid with a new hard disk 118
Setting the boot array in the bios setup utility 119
Rapid storage technology enterprise window 120
Creating a raid set 121
Changing a volume type 123
Deleting a volume 124
Preferences 125
Chapter 6 raid configuration 126
Chapter 7 127
Driver installation 127
C22x intel raid driver 128
C22x intel raid driver windows 32 bit also support ahci windows 64 bit also support ahci back exit 128
Create driver diskette menu c22x intel raid driver write dmi freedos command prompt 128
Creating a raid driver disk 128
Raid driver installation 128
During window 130
Installing the raid controller driver 130
Server 2008 os installation 130
6 chapter 7 driver installation 132
Contact 132
Drivers 132
Makedisk 132
Management applications and utilities installation 132
Manual 132
Running the support dvd 132
The main screen of the support dvd contains the following tabs 132
The support dvd that is bundled with your motherboard contains drivers management applications and utilities that you can install to maximize the features of your motherboard 132
Utilities 132
When you place the support dvd in the optical drive the dvd automatically displays the main screen if autorun is enabled in your computer by default the drivers tab is displayed 132
Drivers menu tab 133
Utilities menu tab 133
Makedisk menu tab 134
Manual menu 134
Chipset device software driver 135
Contact information menu 135
Installing the intel 135
Installing the lan driver 140
Installing the vga driver 145
C22x mei null heci driver 148
Installing the inte 148
I210 gigabit adapter driver 150
Installing the inte 150
Asus contact information 155
Asustek computer inc 155
Asustek computer inc china 155
Asustek computer inc taiwan 155
Technical support 155
Asus computer gmbh germany and austria 156
Asus computer international america 156
Asus contact information 156
Asus czech service s r o europe 156
Technical support 156
Ask service russia and cis 157
Asus contact information 157
Asus holland bv the netherlands 157
Asus polska sp z o o poland 157
Technical support 157

Asus rs100-e8-pi2 Инструкция по эксплуатации онлайн [158/158] 147866

Содержание

Похожие устройства
