Asus rs100-e8-pi2 [44/158] Optical disk drive odd

Chapter 2: Hardware setup

2-26

2.7.2 Optical disk drive (ODD)

To install the optical disk drive:

2. Align the screw hole of the ODD

bracket with the screw hole on the

chassis. Secure the ODD with a

screw.

Optical disk drive slot

1. Slide in the optical disk drive into the

drive slot.

3. Connect the ODD cable to the

optical disk drive.
