SABERTOOTH Z97 MARK 1/USB 3.1
specications summary
Exclusive TUF Features
“SAFE & Stable!” Guardian Angel
- Dust Defenders with connector caps and rear I/O dust lter
- TUF ESD Guards
- MemOK!
Other Special Features
- USB 3.1 Boost featuring speedy USB 3.1/3.0 transmission
- USB BIOS Flashback with USB BIOS Flashback Wizard for EZ
BIOS download scheduling
- USB Charger+ featuring quick-charging function for all smart
devices
- ASUS Remote GO! with Cloud GO! Remote Desktop, Remote
Keyboard and Mouse, and File Transfer
- ASUS UEFI BIOS EZ Mode featuring user-friendly graphics user
interface
- Turbo LAN to experience smooth online gaming with lower pings
and less lags
- Push Notice monitors your PC status with smart devices in real
time
- AI Suite 3
- ASUS Q-Connector
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS O.C. Prole
- ASUS CrashFree BIOS 3
- ASUS EZ Update
- Disk Unlocker
- ASUS EZ Flash 2
- Multi-language BIOS
Rear Panel I/O Ports
1 x DisplayPort
1 x HDMI port
1 x Optical S/PDIF Output
1 x USB BIOS Flashback button
2 x LAN (RJ45) port
2 x USB 3.1/3.0/2.0
2 x USB 3.0/2.0 ports (blue, 1 supports USB BIOS Flashback)
4 x USB 2.0/1.1 ports
8-channel Audio I/O ports
Internal I/O connectors
2 x USB 3.0/2.0 connector support additional 4 USB 3.0/2.0 ports
(moss green)
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
6 x SATA 6.0 Gb/s connectors (2 x brown; 2 x black above the
SATA Express connector, 2 x beige)
