Asus h110m-plus d3 [15/55] Cpu heatsink and fan assembly installation

ASUS H110M-PLUS D3

1-5

1.3.2 CPU heatsink and fan assembly installation

ApplytheThermalInterfaceMaterial

totheCPUheatsinkandCPU

before you install the heatsink and

fan if necessary.
