Asus z170-premium [11/190] Z170 premium specifications summary
![Asus z170-premium [11/190] Z170 premium specifications summary](/views2/1162989/page11/bgb.png)
xi
USB
Intel
®
Z170 Express Chipset- supports ASUS USB 3.1 Boost
- 6 x USB 3.0/2.0 ports (4 ports @mid-board, 2 ports @back panel, blue)
- 6 x USB 2.0/1.1 ports (4 ports @mid-board, 2 ports @back panel, black)
Intel
®
Thunderbolt 3 controller- supports ASUS USB 3.1 Boost and 36W
charging
- 1 x USB 3.1/3.0/2.0 port @back panel (teal blue, Type A)
- 1 x USB 3.1/3.0/2.0 port @back panel (Type C)
ASMedia
®
USB 3.1 controllers- supports ASUS USB 3.1 Boost and 3A power
output
- 1 x USB 3.1/3.0/2.0 port @back panel (teal blue, Type A)
- 1 x USB 3.1/3.0/2.0 port @back panel (Type C)
Wireless Data
Network
Speedy Wi-Fi 802.11 a/b/g/n/ac supports dual frequency band 2.4/5 GHz
Up to 1300 Mbps transfer speed
ASUS Wi-Fi GO! Utility
Bluetooth
Bluetooth v4.0
ASUS Exclusive
Features
Superb Performance
OC Design: ASUS PRO Clock Technology
- Full BCLK range for extreme overclocking performance
5-Way Optimization
- Whole system optimization with a single click! Perfectly consolidates better
CPU performance, power saving, digital power control, system cooling and
app usages
DIGI+ Power Control
- CPU Power: Digital 16-phase power design
- iGPU Power: Digital 4-phase power design
- DRAM Power: Digital 2-phase power design
TPU
- Auto Tuning, GPU Boost, 2-level TPU switch
EPU
- EPU, EPU switch
Fan Xpert 3 featuring Fan Auto Tuning function and multiple thermistors
selection for optimized system cooling control
Turbo App featuring system performance tuning, network priority, and audio
scene conguration for selected applications
UEFI BIOS
- Most advanced options with fast response time
Special Memory O.C. Design
- Superb memory O.C. capability under full load by minimizing the coupling
noise and signal reection effect
PC Cleaner
- Fast and easy way to get rid of unnecessary junk les
(continued on the next page)
Z170-PREMIUM specifications summary
