Asus z170-ws [12/196] Z170 ws specifications summary

xii

USB Intel

Z170 Express Chipset

- 5 x USB 3.0/2.0 ports (4 ports @mid-board, 1 vertical Type A

Connector,blue)

- 6 x USB 2.0/1.1 ports (2 ports @mid-board, 4 port @back panel,

black)

ASMedia

USB 3.0 Hubs

- 4 x USB 3.0/2.0 ports (4 ports @back panel,blue)

ASMedia

USB 3.1 controllers

- 1 x USB 3.1/3.0/2.0 ports @back panel (teal blue, Type A)

- 1 x USB 3.1/3.0/2.0 port @back panel (Type C)

ASUS Exclusive

Features

Superb Performance

OC Design: ASUS PRO Clock Technology

- Full BCLK range for extreme overclocking performance.

5-Way Optimization

- Whole system optimization with a single click! Perfectly

consolidates better CPU performance, power saving, digital power

control, system cooling and app usages.

DIGI+ Power Control

-CPU Power: Digital 8-phase power design

-iGPU Power: Digital 4-phase power design

-DRAM Power: Digital 2-phase power design

TPU

- Auto Tuning, GPU Boost, 2-level TPU switch

EPU

- EPU, EPU switch

Fan Xpert 3 featuring Fan Auto Tuning function and multiple

thermistors selection for optimized system cooling control

Turbo App featuring system performance tuning, network priority,

and audio scene conguration for selected applications.

UEFI BIOS

- Most advanced options with fast response time

Special Memory O.C. Design

- Superb memory O.C. capability under full load by minimizing the

coupling noise and signal reection effect

PC Cleaner

- Fast and easy way to get rid of unnecessary junk les

(continued on the next page)

Z170-WS specifications summary
