ASUS N3150I-C / N3050I-C
1-15
8. System panel connector (10-1 pin F_PANEL)
Thisconnectorsupportsseveralchassis-mountedfunctions.
• System power LED (2-pin PWRLED)
This2-pinconnectorisforthesystempowerLED.ConnectthechassispowerLED
cabletothisconnector.ThesystempowerLEDlightsupwhenyouturnonthesystem
power,andblinkswhenthesystemisinsleepmode.
•
Hard disk drive activity LED (2-pin +HDLED)
This2-pinconnectorisfortheHDDActivityLED.ConnecttheHDDActivityLEDcable
tothisconnector.TheHDLEDlightsuporasheswhendataisreadfromorwrittento
theHDD.
•
ATX power button/soft-off button (2-pin PWRBTN)
This connector is for the system power button.
•
Reset button (2-pin RESET)
This 2-pin connector is for the chassis-mounted reset button for system reboot without
turning off the system power.
N3050I-C
N3150I-C / N3050I-C System panel connector
PIN 1
PWR_BTN
PWR_LED+
PWR_LED-
PWR
GND
HDD_LED+
HDD_LED-
Ground
HWRST#
(NC)
F_PANEL
+PWR LED-
+HDD_LED- RESET
N3150I-C
9. LVDS connector (40-pin LVDS)
ThisconnectorisforanLCDmonitorthatsupportsLow-voltageDifferentialSignaling
(LVDS)interface.
N3050I-C
N3150I-C / N3050I-C LVDS connector
LVDS
PIN 1
N3150I-C
TheLVDSoutputisdisabledbydefault.ToconnectaLVDSmonitor,settheIGD Flat
Panel itemintheBIOSsetupto[LVDS].Seesection2.5.3 SoC Conguration for details.
