ASUS B150I PRO GAMING/AURA SERIES
1-27
3. SupremeFX LED
TheSupremeFXLEDlightsupinthefollowingthreewaystobringyouanultimate
lightingeffect.ThisLEDalsooutlinestheseparationoftheaudiocomponentsfromthe
rest of your motherboard.
Lit mode Description
Breathingmode TheLEDblinksintermittently.
Still mode TheLEDbecomessolidred.
YoucanturnofftheSupremeFXLEDorchangethelitmodesfromtheBIOSortheLED
ControlappinAiSuite3.TochangethesettinginBIOS,gotoMy Favorites > Onboard
DevicesConguration > SupremeFX LED Lighting item. See section 2.6.7 Onboard
DevicesCongurationfor details.
