8 Getting to know your monitor
Input and output ports
Available input and output ports may vary depending on your purchased model. Check the
Specification document on the provided CD for details.
Models with dual inputs 1. AC power input jack
2. HDMI sockets
3. DVI-D socket
4. D-Sub socket
5. Headphone jack
Models with HDMI inputs
1 3 4
1 4
5
2
