Netis WF2411 Технические характеристики онлайн
Brief:
The netis WF2411 mbined wired and wireless device for SOHO network applications.
It’s compatible with 802.11b/g/n devices and provides the wireless transfer speed up to 150Mbps, offering a better
performance on web surfing, emailing, and file sharing. It also supports multi-wireless modes including AP, WDS,
AP+WDS, Repeater, Client, to expand your wireless network easily. With the Setup CD and WPS button, it can help you
to build your wireless network in a snap.
150Mbps Wireless N Router is a co
WF2411
150Mbps Wireless N Router
Easy Network, Trustable
>Multi-wireless modes to expand the wireless network: AP, WDS, AP+WDS, Client, Repeater
Features:
>Wireless N speed up to 150Mbps
>Easy wireless security encryption with single WPS button
>5dBi high gain antenna provides better wireless signal coverage and reception
> sFast setup the router and configure Repeater & Wireless with the etup CD
QoS
150Mbps
5dBi
WDSWISP
Repeater
Multi SSID
WPS
Easy
Setup
64 /128-bit WEP WPA-PSK/WPA2-PSK (TKIP/AES) SSID Broadcast Enable/Disable Wireless MAC Filtering
Wireless Security
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wireless
Standard
Signal Rate
Frequency Range
Transmit Power
Up to 150Mbps
2.4-2.4835GHz
20dBm (MAX)
Data Transfer Rate
802.11n: 40MHz (150Mbps, 135Mbps, 120Mbps, 90Mbps, 60Mbps, 45Mbps, 30Mbps, 15Mbps)
20MHz (72Mbps, 65Mbps, 57Mbps, 43Mbps, 28Mbps, 21Mbps, 14Mbps, 7Mbps)
801.11g: (54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)
802.11b: (11Mbps, 9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)
Wireless Mode
AP, WDS, AP+WDS, Repeater, Client, Multiple AP
Dimensions(L x W x H )
149g
Weight
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
Hardware
Standard
Interface
LED
Button
1 * 10/100M Auto MDI/MDIX RJ45 WAN port
4 * 10/100M Auto MDI/MDIX RJ45 LAN port
SYS,WPS, WAN, LAN1-LAN4
Default, WPS
DC 9V/500mA (Output)
133 x 99 x 27 mm
Power Supply
Others
DHCP(Dynamic IP), PPPoE, Static IP, WISP
Software
WAN Type
Port Forwarding
QoS
Access Control
Virtual Servers, Port Triggering, UPnP, DMZ, FTP Private Port
WMM, Bandwidth Control
IP/ MAC/ Domain filtering
PPTP, L2TP, IPSEC
DDNS, Static Routing, WOL, Remote Management, Firmware upgrade
VPN Pass-through
FCC, CE, KC
Others
Certification
Environment
Package
1 *WF2411 1 *Setup CD 1 * Power Adapter 1 * Ethernet Cable 1 *Quick installation Guide
Specifications are subject to change without notice. Netisis a registered trademark of Netis Systems Co., Ltd. Other brands and product names are trademarks or
registered trademarks of their respective holders. No part of the specifications maybe reproduced in any form or by any means or used to make any derivative such
as translation, transformation, or adaptation without permission fromNetis Systems Co., Ltd.
WF2411
150Mbps Wireless N Router
Antenna
1 * external 5dBi antenna
DL4102
Internet
Wired
Wireless
150Mbps Wireless N Router
WF2411
WF-2111
WF2120
WF-2117
WF2120
150Mbs Wireless N NANO USB Adapter
WF-2111
150Mbs Wireless N USB Adapter
WF-2117
150Mbs Wireless N PCI Adapter
Related products
DL4102
Wired ADSL2+ Modem
Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Specification:
Topological Graph:
