Netis DL4323D Инструкция по эксплуатации онлайн
Brief:
The netis DL4323D is a 3-in-1 device that combines the functions of a high speed ADSL2+ modem, 4-port NAT router
and wireless N access point. It is designed to provide end-users with a one-stop solution to acquiring and sharing high-
speed Internet access over a wired/wireless network. Supporting the latest ADSL standards, the DL4323D brings with
it much higher speed than dial-up connections. It also provides some practical functions, such as Port Mapping for
IPTV, Ethernet WAN, SNMP, IPv6, TR-069 and more. With this product, users can now enjoy more kinds of heavy
bandwidth consuming applications like wireless HD video streaming.
Easy Network, Trustable
300Mbps Wireless N
ADSL2+ Modem Router
Features:
>High speed ADSL2+ modem, 4-port NAT router and wireless N access point in one device
>ADSL2/2+ standards ensuring high-speed Internet access up to 24Mbps downstream
>Powerful wireless N speed up to 300Mbps
>Port mapping function ensuring wonderful IPTV experience
>Ethernet WAN offers additional connectivity option for Cable or Fiber modem
>Built-in firewall to safeguard home network from potential Internet attacks
>IPv6 supported for improved network usability and experience
>4KV super lightning protection to avoid device damage caused by tough thunderstorms
>5dBi detachable antenna for wide range and convenient upgrade
>Easy setup wizard providing quick and hassle free installationhassle free installation
DL4323D
Specifications are subject to change without notice. Netisis a registered trademark of Netis Systems Co., Ltd. Other brands and product names are trademarks or
registered trademarks of their respective holders. No part of the specifications maybe reproduced in any form or by any means or used to make any derivative such
as translation, transformation, or adaptation without permission fromNetis Systems Co., Ltd.
DL4323D
300Mbps Wireless N ADSL2+ Modem Router
Topological Graph:
CE, FCC
Others
Certification
Environment
Package
1 * DL4323D 1 * 12V/500mA Power Adapter 2 * RJ11 Telephone Cable 1 * RJ45 Ethernet Cable
1 * ADSL Splitter 1 * Quick Installation Guide(Multilingual)
Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90%RH non-condensing Storage Humidity: 5%~90%RH non-condensing
Specification:
1 * RJ11 ADSL Port,
4 * 10/100Mbps Auto MDI/MDIX RJ45 LAN Port(Optional Ethernet WAN for LAN4)
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
Hardware
PWR, LAN4, LAN3, LAN2, LAN1, WLAN, WPS, ADSL, Internet
DC 12V/500mA (Output)
WPS, Default, Power ON/OFF
Interface
Ethernet Standards
LED
Power Supply
Button
144.5 * 90 * 26.5mm
WPS, Default, Power ON/OF
Dimensions (L x W x H )
ADSL, ADSL2, ADSL2+
Software
ADSL Version
Data Rate
ATM/PPP Protocol
Downstream: Up to 24Mbps
Upstream: Up to 1Mbps
ATM Forum UNI3.1/4.0 PVC (up to 8PVCs) ATM Adaptation Layer Type 5 (AAL5)
ATM QoS Bridged and Routed Ethernet Encapsulation
VC and LLC Based Multiplexing PPP over Ethernet (RFC2516)
PPP over ATM (RFC 2364) IPoA (RFC1577/2225)
Main Feature
DHCP, DHCP Relay NAT, Static Routing
VPN (PPTP, L2TP, IPsec) Pass-through PVC/Ethernet Port Mapping
DNS Relay, DDNS IGMP Multicast, IGMP Snooping V1/V2
Virtual Server, DMZ, ACL (Access Control List) UPnP
IPv6
Management
Web Based Configuration (HTTP), Remote Management, Telnet Management, Command Line Interface,
TR-069, SNMP, Web Based Firmware Upgrade, CWMP (TR-069), Diagnostic Tools
Wireless Standards
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Frequency Range
2.4-2.4835GHz
Wireless Speed
Up to 300Mbps
Wireless Security
WEP 64/128bits WPA(TKIP/AES)/WPA2(TKIP/AES)/WPA2 Mixed,
802.1x Authentication Wireless MAC Filtering
Wired
Wireless
Internet
WF2120
150Mbps Wireless N Nano USB Adapter
WF2111
150Mbps Wireless N USB Adapter
WF2117
150Mbps Wireless N PCI Adapter
Related products
300Mbps Wireless N ADSL2+ Modem Router
DL4323D
WF2120
WF2111
WF2117
2 * 5dBi Detachable Antennas, SMA Connector
Antennas Type
Wireless Security Power
20dBm
Mbps
300
Firewall
QoS
Easy Setup
ADSL2+
Lightning Protection
4000V4000V
3-in-1
WPS
IPTV
Ethernet WAN
Compatible with
Detachable
5dBi
5dBi
Multi SSID
Repeater
Dual Access
Mbps
150
Access Control
Mbps
300
Windows
8
Dual Band
WPS
Gigabit
QoS
MAC OS
Long Range
Soft AP
PCIPCI-E
WISP
Detachable
5dBi
Slim Body
Linux
Dual Profile
USB 3.0
867
Mbps
Easy Setup
Ethernet WAN
IPTV
All-in-One
ADSL2+
ADSL2+
Firewall
Easy Setup Easy to Use
IPTV
Compact Design
QoS
Easy Setup
Easy to Use
Ethernet WAN
ADSL2+
Compact Design
OROR
2dBi
Lightning Protection
4000V4000V
Ethernet WAN
ADSLADSL
EWANEWAN
2-in-1
Ethernet WAN
WANWAN
LANLAN
10dBi
15KV ESDSignal ButtonCeiling-Mounted
IEEE
AP Router Wi-Fi Extender Mobile InterfaceWall Mount
WDS
PoE
12dBi
High Power
Nano
Weatherproof
Passive
Passive
802.3af
802.3af
PoE
Storage Sharing
Ceiling-Mounted
Group Button
100Mbps
PCIPCI
1000Mbps1000Mbps
PCIPCI
Win8 & 8.1
300
Meters
Windows
Web Browsing E-mailing
File Sharing
Downloading
Video Chatting Online Gaming
Internet Calling Video Streaming Audio Streaming
应用
设备
IPTV
Bridge
WANWAN
LANLAN
Wi-Fi ON/OFF
3-in-1
802.3af
802.3af
High Power
802.11
PoE PoE
15KV ESD
200Mbps
