Cells Per Unit 6

Voltage Per Unit 12

Capacity 7.2Ah @ 20hr-rate to 1.75V per cell @25°C (77°F)

Weight Approx. 2.4 kg(5.29 lbs)

Maximum Discharge Current 100A/130A(5sec)

Internal Resistance Approx. 23 mΩ

Operating Temperature Range

Nominal Operating Temperature Range

Float Charging Voltage

Recommended Maximum Charging 2.16A

Current Limit

Equalization and Cycle Service

Self Discharge CSB Batteries can be stored for more than 6 months at

Please charge batteries before using. For

higher temperatures the time interval will be shorter.

Terminal F1/F2-Faston Tab187/250

Container Material ABS(UL 94-HB) & Flammability resistance of

(UL 94-V0) can be available upon request.

Discharge:

Charge:

Storage:

Constant Power Discharge Characteristics Unit:W (25°C,77°F)

Constant Current Discharge Characteristics Unit:A (25°C,77°F)

GP 1272

12V 7.2Ah

Specification

GP 1272 is a general purpose battery up to 5 years in standby

service or more than 260 cycles at 100% discharge in cycle

service. As with all CSB batteries, all are rechargeable, highly

efficient, leak proof and maintenance free.

Width (W)

Dimensions :

Unit: mm (inch)

Overall Height (H) Container height (h) Length (L)

100±1 (3.94±0.04) 94±1 (3.7±0.04) 151±2 (5.94±0.08) 65±1 (2.56±0.04)

13.5 to 13.8 VDC/unit Average at

14.4 to 15.0 VDC/unit Average at

CSB-manufactured

VRLA batteries are UL-

recognized components

under UL924 and UL1989.

CSB is also certified by

ISO 9001 and ISO 14001.

(http://www.csb-battery.com)

by TUV CERT according to ISO 9001,ISO 14001.

The system of manufacturer was certified

F.V/Time 5MIN 10MIN 15MIN 30MIN 60MIN 90MIN 2HR 3HR 5HR 8HR 10HR 20HR

1.60V

35.6 22.0 16.5 9.61 5.51 3.92 3.08 2.13 1.34 0.92 0.77 0.45

1.67V

33.1 21.0 15.9 9.36 5.41 3.85 3.02 2.08 1.31 0.90 0.76 0.44

1.70V

31.9 20.5 15.6 9.24 5.37 3.82 3.00 2.06 1.30 0.89 0.75 0.43

1.75V

29.6 19.6 15.1 9.03 5.30 3.77 2.96 2.02 1.27 0.88 0.74 0.42

1.80V

27.2 18.6 14.4 8.77 5.23 3.71 2.91 1.98 1.25 0.87 0.73 0.42

1.85V

24.5 17.4 13.7 8.44 5.14 3.66 2.87 1.95 1.22 0.86 0.71 0.40

F.V/Time 5MIN 10MIN 15MIN 30MIN 60MIN 90MIN 2HR 3HR 5HR 8HR 10HR 20HR

1.60V

360 245 183 108 64.4 47.1 37.7 26.6 17.3 11.8 9.80 5.37

1.67V

340 235 177 106 63.6 46.4 37.1 26.3 17.0 11.6 9.68 5.27

1.70V

331 231 174 105 63.1 46.1 36.9 26.2 16.9 11.5 9.54 5.23

1.75V

313 222 170 103 62.4 45.5 36.4 25.9 16.7 11.4 9.47 5.15

1.80V

295 213 165 101 61.7 45.0 35.9 25.6 16.5 11.3 9.40 5.07

1.85V

276 202 158 99 60.8 44.3 35.4 25.2 16.3 11.2 9.29 4.99

25°C (77°F)

25°C (77°F).

-15°C~50°C ( 5°F~122°F)

-15°C~40°C ( 5°F~104°F)

25°C±3°C (77°F±5°F)

RA1210

Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
