5 di 14
This kind of redundancy must guarantee continuous supply and protection whenever one module fails.
Redundancy must be obtained through the load sharing technology as explained in paragraph 2.5.
2.4 Scalabilty
The modularity of the UPS must allow to increase the back-up time on site, simply adding battery
drawers. The upgrade will not require factory modifications and will not need dedicated special tools.
2.5 Architetture
The architecture of the UPS must be parallel distributed, to be more precise, the load will be shared
between all power modules in each phase. In this way, during normal run, no power module is inactive or
in standby. In a redundant configuration, if one moduel fails all the others ones will take the relevant load
without any interruptions or transfer time at the output of the UPS. In case one module failure the power
is guaranteed by the others modules and the supplied power will been s follows:
n
xn
PP
nomout
)( −
=
in single phase configuration
and
n
xn
PP
nomout
)3( −
=
in three phase configuration
where
•
nom
P
is the nominal power of the UPS;
• is the power supplied by the UPS with one module out of order;
•
n
is the number of installed power modules inside the UPS;
• x is the number of power modules out of order;
3 DESCRIPTION OF THE SYSTEM
3.1 POWER MODULE
Each Power Module will be composed by following functional blocs:
! Inverter
! Booster
! Battery Charger
! Rectifier/PFC
out
P
